Professional ESD Safe Tools Datasheet by Wiha

wihao Tools that work for you PROFESSIONAL ESD SAFE TOO

Static Dissipative

2019

PROFESSIONAL ESD SAFE TOOLS

COMPLETE ESD

SAFE PROGRAM

Precision Screwdrivers • Micro Bits • Precision Bit Holders • Cushion Grip Drivers

Blade Sets • Calipers • TorqueControl • Pliers & Cutters • Wire Strippers • Tweezers

For

working on

static sensitive

electronic

components!

wihao Tools that work 10! you

2

Description Page

Drive-Loc IV Handle 7-8

Drive-Loc IV Sets 7

ESD Safe Drive-Loc IV Handles/Blades/Sets

Description Page

Prec. Slotted/Phillips 4-5

Prec. Torx/TorxPlus 5

Prec. Hex Screwdrivers 6

Prec. Nut Drivers 6

ESD Safe Precision Screwdrivers

What is ESD?

Basic Concepts in Electrostatic Discharge (ESD)

We have all seen static electricity in the form of lightning or perhaps felt

the zap when reaching for a door knob. Similar types of electrical charges

can have an effect on the electronic components you handle every day in

your work. Unfortunately, their effect is much more hazardous and not as

readily apparent.

Definition

Static electricity is an electrical charge at rest. Static electricity is most

commonly created by friction and separation. Friction causes heat which

excites the molecular particles of the material. When two materials are

then separated, a transfer of electrons from one material to the other may

take place.

As electrons transfer, the absence or surplus of electrons creates an

electrical field known as static electricity. The simple separation of two

materials, as when tape is pulled off a roll, can also create this same

transfer of electrons between materials, generating static electrical fields.

The amount of static electricity generated depends upon the materials

subjected to friction or separation, the amount of friction or separation

and the relative humidity of the environment. Common plastic generally

will create the greatest static charge. Low humidity conditions such as

those created when air is heated during the winter will also promote the

generation of significant static electrical charges.

Materials that easily transfer electrons (or charge) between atoms are

called conductors and are said to have “free” electrons. Some examples of

conductors are metals, carbon and the human body’s sweat layer. Materials

that do not easily transfer electrons are called insulators. Some well

known insulators are common plastics, glass and air. Both conductors and

insulators may become “charged” with static electricity. When a conductor

is charged, the free electrons give it the ability to discharge rapidly when it

comes close to another conductor with a different potential.

Typical Electrostatic Voltages

Many of the common activities you perform daily may generate charges on

your body that are potentially harmful to components.

Some of these activities include:

· Walking across a carpet, 1,500 to 35,000 volts

· Walking over untreated vinyl floor, 250 to 12,000 volts

· Worker at a bench, 700 to 6,000 volts

· Vinyl envelope used for work instructions, 600 to 7,000 volts

· Picking up a common plastic bag from a bench, 1,200 to 20,000 volts

Costly Effects of ESD

When you feel a static shock, you are experiencing a minimum of 3,000 volts

of electricity.

This “shock” known as Electro Static Discharge or ESD also may be

responsible for damaging many of the rejected electronic components in

your company.

While you can feel electrostatic discharges of 3,000 volts, smaller charges

are below the threshold of human sensation. Unfortunately, smaller

charges can and do damage semiconductor devices. Many of the CMOS

technology components used in your facility can be damaged by charges

of less than 1,000 volts. Some of the more sophisticated components can

be damaged by charges as low as 10 volts. You should be aware of the

relative sensitivity to ESD damage of devices you may be working with.

As electronic technology advances, electronic components tend to become

smaller and smaller. As the size of the components is reduced, so is the

microscopic spacing of insulators and circuits within them, increasing their

sensitivity to ESD. As you can predict, the need of proper ESD protection

increases everyday.

Types of ESD Damage

Static damage to components can take the form of upset failures or

catastrophic failures.

· Upset failures - result in gate leakage

· Catastrophic failures - occur in two forms, Direct and Latent

Direct catastrophic failures occur when a component is damaged to the point

where it is DEAD NOW & it will never again function. This is the easiest type

of ESD damage to find since it usually can be detected during testing.

Latent failures occur when ESD weakens or wounds the component to the

point where it will still function properly during testing, but over time the

wounded component will cause poor system performance and eventually

complete system failure. Because latent failures occur after final inspection

or in the hands of your customer, the cost for repair is very high. Not only

is this type of damage hard to find, but it severely affects the reputation of

your company’s product.

An upset failure occurs when an electrostatic discharge has caused

a current flow that is not significant enough to cause total failure, but in

use may intermittently result in gate leakage causing loss of software or

incorrect storage of information.

Upset or latent failures may pass your company’s quality control testing

program. In other words, static damage may occur that cannot be felt,

seen, or detected through normal testing procedures.

Think of Static As Contamination!

Damage caused by invisible and undetectable events can be understood

by comparing ESD damage to medical contamination of the human body

by viruses or bacteria. Although viruses and bacteria are invisible, they

can cause severe damage even before you can detect their presence. A

defense against this invisible threat is sterilization.

As an employee, the hidden threat of electrostatic discharge or ESD should

be of great concern to you. ESD damage can significantly reduce your

company’s profitability. This may affect your profit sharing, your company’s

ability to compete in the market place and even your employment. Everyone

likes to take pride in their work, but without proper ESD controls, your best

efforts may be destroyed by static electricity that you can neither feel nor see.

This Article courtesy of Desco Industries, Inc

Toll Free: (800) 494-6104

.h Tools that work 10! you _ mm” _ _ . ﬁéﬁ 5;. , 3 w E -

3

Description Page

TorqueControl Drivers 17

TorqueControl Blades 17

ESD Safe TorqueControl Tools

Description Page

Calipers 13

ESD Safe Calipers Index

Description Page

Diagonal Cutters 18

Diagonal Cutters 18-19

Diagonal Cutters 19

Oblique Angled Cutters 19-20

End Cutters 20

Pliers 20-21

Tapered Head

Wide Tapered & Oval Head

Wide Oval & Wide Form

Carbide Edge

ESD Safe Pliers & Cutters Index

Description Page

SoftFinish® Slotted Drivers 14

SoftFinish® Phillips Drivers 14

SoftFinish® Torx® Drivers 14

ESD Safe Cushion Grip Screwdrivers

ESD Safe Drive-Loc VI Blade Sets

Description Page

Tweezers 23-25

ESD Safe Tweezers Index

Description Page

Drive-Loc VI 15-16

ESD Safe Drive-Loc VI Handle & Blades

Description Page

Micro Bits 8-12

ESD Safe Micro Bit Handles/Bits & Sets

Description Page

Micro Bit Sets 12

ESD Safe SYS 4 ESD Safe Micro Bit Sets

Description Page

Proturn Wire Strippers 21

Proturn Pliers 22

Precision Cutters/Flush Cut 22

Long, Flat, Bent, Round Nose

ESD Safe Proturn Pliers & Cutters Index

Description Page

Drive-Loc VI ESD Sets 16

21° & 45° Angle

30 to 20 AWG

Description Page

SoftFinish® Bit Holders 13

Quick Release Bit Holder 13

ESD Safe Cushion Grip Bit Holders

Handle, Blades & Set

www.wihatools.com

wihao Tools [hat work fol you n ::'_ \ \§m 0 {I :-=-:= =2“- hard chromed. Handle manufactured tram Storage pouch. ESD slandald \EC 613407571. ‘ m @ . \E‘ n 0 0 - - ESD slandavd \EC 613407571 m m

4

Precision ESD Safe Dissipative Screwdrivers

Slotted Screwdriver, With Precision

ESD Safe Dissipative Handle Blade high

alloy CVM steel. Hard chrome finished.

Handle manufactured from impact resistant,

dissipative material. ESD standard IEC 61340-5-1.

Item

No. mm Inch mm Inch mm mm Inch

.8 1/32 40 1.6 0.16 120 4.7

1.0 .039 40 1.6 0.18 120 4.7

1.2 3/64 40 1.6 0.20 120 4.7

1.5 1/16 40 1.6 0.25 120 4.7

1.8 5/64 40 1.6 0.30 120 4.7

2.0 5/64 40 1.6 0.40 120 4.7

2.0 5/64 75 3.0 0.40 155 6.1

2.0 5/64 100 3.9 0.40 180 7.1

2.0 5/64 150 5.9 0.40 260 10.2

2.5 3/32 50 2.0 0.40 145 5.7

2.5 3/32 100 3.9 0.40 195 7.7

2.5 3/32 150 5.9 0.40 245 9.6

3.0 1/8 50 2.0 0.50 145 5.7

3.0 1/8 100 3.9 0.50 210 8.3

3.0 1/8 150 5.9 0.50 260 10.2

3.5 9/64 60 2.4 0.60 170 6.7

3.5 9/64 100 3.9 0.60 210 8.3

3.5 9/64 150 5.9 0.60 260 10.2

4.0 5/32 60 2.4 0.80 170 6.7

4.0 5/32 100 3.9 0.80 210 8.3

4.0 5/32 150 5.9 0.80 260 10.2

*Metric dimensions actual - Inch dimensions approximate

Molded Precision handle

Impact resistant dissipative material

Tapered handle allows rapid rotation

Blade CVM steel, hardened, hard chrome finish

Tip Precision ground for exact fit, Wiha Chromtop finish

Rotating cap

For precise turning & control with fingertip

Wiha Precision ESD Static Dissipative Screwdrivers

meet the requirements for tools used in static sensitive areas

Surface resistance of handles is 106 - 109 Ohms

Set 7 Pcs. Slotted & Phillips

Precision ESD Safe Dissipative Handle

Blade high alloy CVM steel, hardened,

hard chrome. Handle manufactured from

impact resistant, dissipative material.

ESD standard IEC 61340-5-1

Item Slotted:

No. 1.5, 2.0, 2.5, 3.5mm lbs.

Phillips: .30

#00, 0, 1

Set 8 Pcs. Slotted Precision ESD

Safe Dissipative Handle In storage pouch.

Item Slotted:

No. .8, 1.0, 1.2, 1.5, lbs.

2.0, 2.5, 3.0, 3.5mm .54

ESD Standard IEC 61340-5-1

Phillips Screwdriver, With Precision

ESD Safe Dissipative Handle Blade high

alloy chrome-vanadium-molybdenum steel.

Hard chrome finished. Handle manufactured

from impact resistant, dissipative material.

ESD standard IEC 61340-5-1.

Item

No. Size mm Inch mm Inch mm Inch

000 40 1.6 2.0 .08 120 4.7

00 40 1.6 2.0 .08 120 4.7

00 75 3.0 2.0 .08 155 6.1

0 50 2.0 3.0 .12 145 5.7

0 100 3.9 3.0 .12 195 7.6

0 150 5.9 3.0 .12 245 9.6

1 60 2.3 4.0 .16 170 6.7

1 75 3.0 4.0 .16 155 6.1

1 100 3.9 4.0 .16 210 8.2

1 150 5.9 4.0 .16 260 10.2

*Metric dimensions actual - Inch dimensions approximate

Set 8 Pcs. Slotted & Phillips

Precision ESD Safe Dissipative Handle

Blade high alloy CVM steel, hardened,

hard chromed. Handle manufactured from

impact resistant, dissipative material.

Storage pouch. ESD standard IEC 61340-5-1.

Item Slotted:

No. 1.5, 2.0, 2.5, 3.0mm lbs.

Phillips: .50

#000, 00, 0, 1

Set 7 Pcs. Extra Long Slotted/

Phillips Precision ESD Safe Dissipative

Handle Blade CVM steel, hardened, hard

chromed. Handle impact resistant, dissipative

material. ESD standard IEC 61340-5-1

Item Slotted:

No. 2.0, 2.5, 3.0, 3.5, 4.0mm lbs.

Phillips: .50

#0, 1

D

Set 7 Pcs. Slotted & Phillips

Precision ESD Safe Dissipative Handle

Blade high alloy CVM steel, hardened,

hard chrome. Handle manufactured from

impact resistant, dissipative material.

ESD standard IEC 61340-5-1

Item Slotted:

No. 1.5, 2.0, 2.5, 3.5mm lbs.

Phillips: #00, 0, 1 .60

6.5” Long Nose Pliers W/Cutters

D

lbs. pkg.

.02 10

.03 10

.04 10

.05 10

.06 10

.07 10

lbs. pkg.

.02 10

.04 10

.05 10

.06 10

.07 10

27208

27210

27212

27215

27218

27220

27222

27223

27224

27225

27227

27228

27230

27232

27234

27235

27237

27238

27240

27242

27243

27290

272

27290

27390

27302

27305

27307

27310

27314

27316

27320

27322

27324

27326

273

27399

27393

27398

Toll Free: (800) 494-6104

wihao Tools [hat work fol you 0_ — 0R7 — -m -1mxplus~ mamna‘ ESD standard IEC 613407571. — o=-=-:—_-n— I} 'Memc mmensms amua‘ , mm mmensmns approxxmate mm malenal. In storage pouch

5

Set 7 Pcs. Precision

ESD Safe Dissipative Handle Blade high

alloy CVM steel, hardened, hard chromed.

Item :

No. IP5, IP6, IP7, IP8 lbs.

IP9, IP10, IP15 .27

ESD Safe Dissipative Precision Screwdrivers

Surface resistance of handles is 106 - 109 Ohms

Master Technicians Bench Top Set

Metal frame. Equipped with 50 precision ESD

Safe screwdrivers.

Item Slotted: .8, 1.0, 1.2, 1.5, 2.0, 2.5,

No. 3.0, 3.5, 4.0mm

Phillips: #000, #00, #0, #1

: T1, T2, T3, T4, T5, T6,

T7, T8, T9, T10, T15, T20

lbs. Metric Hex: .7, .9, 1.3, 1.5, 2.0,

2.25 2.5, 3.0, 4.0mm

Inch Hex: 1/16, 5/64, 3/32, 7/64,

1/8, 9/64, 5/32”

Metric Nut Drivers: 1.5, 2.0, 2.5,

3.0, 3.5, 4.0, 4.5, 5.0, 5.5mm

27920 Chip Lifter

ESD

standard

IEC

61340-5-1

Set 7 Pcs. Precision ESD

Safe Dissipative Handle

Blade high alloy CVM steel, hardened, hard

chromed. Handle manufactured from impact

resistant, dissipative material.

Item :

No. T4, T5, T6, T7, lbs.

T8, T9, T10 .31

Set 8 Pcs. Precision

ESD Safe Dissipative Handle Set In Pouch

Blade high alloy CVM steel, hardened, hard

chromed. Handle impact resistant, dissipative

material. In storage pouch.

Item :

No. T1, T2, T3, T4, lbs.

T5, T6, T7 .47

Chip Lifter

Screwdriver, With Precision

ESD Safe Dissipative Handle Blade high

alloy CVM steel. Hard chrome finished.

Handle impact resistant, dissipative material.

ESD standard IEC 61340-5-1.

Item

No. Size mm Inch mm Inch lbs. pkg.

T1 40 1.6 120 4.7 .03 10

T2 40 1.6 120 4.7 .03 10

T3 40 1.6 120 4.7 .03 10

T4 40 1.6 120 4.7 .03 10

T5 40 1.6 120 4.7 .03 10

T6 40 1.6 120 4.7 .03 10

T7 40 1.6 120 4.7 .03 10

T8 40 1.6 120 4.7 .03 10

T9 50 2.0 145 5.7 .04 10

T10 50 2.0 145 5.7 .04 10

T15 60 2.4 170 6.7 .07 10

T20 60 2.4 170 6.7 .07 10

*Metric dimensions actual - Inch dimensions approximate

ESD standard IEC 61340-5-1

D

Screwdriver, With

Precision ESD Safe Dissipative Handle

Blade high alloy CVM steel, hardened, hard

chromed. Handle impact resistant, dissipative

material. ESD standard IEC 61340-5-1.

Item

No. Size mm Inch mm Inch lbs. pkg.

IP4 40 1.6 120 4.7 .03 10

IP5 40 1.6 120 4.7 .03 10

IP6 40 1.6 120 4.7 .03 10

IP7 40 1.6 120 4.7 .03 10

IP8 40 1.6 120 4.7 .03 10

IP9 50 2.0 145 5.7 .04 10

IP10 50 2.0 145 5.7 .04 10

IP15 60 2.4 170 6.7 .07 10

*Metric dimensions actual - Inch dimensions approximate

ESD standard IEC 61340-5-1

Precision Chip Lifter - ESD Safe

Blade CVM steel, hardened, corrosion resistant

finish. Precision handle high quality plastic,

Dissipative material.

Item

No. mm mm mm mm Inch lbs. pkg.

1 3.5 50 145 5.7 .07 1

Wiha Precision ESD Safe

Chip Lifter

Surface resistance of handles

is 106 - 109 Ohms

D

Smartphone ESD Safe/Standard

Precision Set, 11 Piece

Blade high alloy CVM steel, hardened, hard

chromed. Storage pouch.

Item ESD Safe Screwdrivers:

No. Slotted: 1.5mm

Phillips: #000, #00, #0

: T3, T4, T5, T6

lbs. Tweezers: PSF SA ESD Long

Flat Tweezers

Standard Precision Screwdrivers:

Pentalobe: PL1

Tri-Wing: #000

92092

27801

27802

27803

27804

27805

27811

27817

27823

27829

27835

27841

27847

278

27890

27899

27850

27851

27852

27853

27854

27855

27856

27857

278

27894

27920

27397

www.wihatools.com

wihao Tools [hat work fol you Hal IEC 613407571. m . =- =-—_- =m - =-=-—_-—_-n— HM He! 0 , Blade CVM sleel, hardened, hard chromed. _L

6

Hex Metric Driver, With

Precision ESD Safe Dissipative Handle

Blade high alloy CVM steel. Hard chrome

finished. Handle manufactured from impact

resistant, dissipative material. ESD standard

IEC 61340-5-1.

Item

No. mm mm Inch mm Inch lbs.

0.7 40 1.6 120 4.7 .02

0.9 40 1.6 120 4.7 .02

1.3 40 1.6 120 4.7 .03

1.5 50 2.0 145 5.7 .03

2.0 50 2.0 145 5.7 .04

2.5 60 2.4 170 6.7 .05

3.0 60 2.4 170 6.7 .05

4.0 60 2.4 170 6.7 .05

*Metric dimensions actual - Inch dimensions approximate

Hex Inch Driver, With Precision

ESD Safe Dissipative Handle

Item

No. Inch mm Inch mm Inch

0.028 40 1.6 120 4.7

0.035 40 1.6 120 4.7

0.05 40 1.6 120 4.7

1/16 50 2.0 145 5.7

5/64 50 2.0 145 5.7

3/32 60 2.4 170 6.7

7/64 60 2.4 170 6.7

1/8 60 2.4 170 6.7

9/64 60 2.4 170 6.7

5/32 60 2.4 170 6.7

*Metric dimensions actual - Inch dimensions approximate

Set 8 Pcs. Hex Inch Precision

ESD Safe Dissipative Handle Blade CVM

steel, hardened, hard chromed. Handle impact

resistant, dissipative material. Storage pouch.

Item Hex Inch:

No. .050, 1/16, 5/64, 3/32, lbs.

7/64, 1/8, 9/64, 5/32” .57

Wiha Precision ESD Safe Dissipative Hex Screwdrivers ESD standard IEC 61340-5-1

Surface resistance of handles is 106 - 109 Ohms

Metric Nut Driver, With Precision

ESD Safe Dissipative Handle Blade high

alloy CVM steel. Hard chromed finished.

Item

No. mm mm Inch mm Inch Inch

1.5 60 2.4 140 2.5 3.0

1.8 60 2.4 140 2.9 3.5

2.0 60 2.4 140 3.2 4.0

2.5 60 2.4 140 4.0 4.0

3.0 60 2.4 155 5.0 5.0

3.5 60 2.4 155 5.3 6.0

4.0 60 2.4 155 5.5 6.0

4.5 60 2.4 155 6.2 7.0

5.0 60 2.4 155 6.8 7.0

5.5 60 2.4 170 7.6 8.0

6.0 60 2.4 170 9.6 10.0

*Metric dimensions actual - Inch dimensions approximate

Inch Nut Driver, With Precision

ESD Safe Dissipative Handle Blade high

alloy CVM steel. Hard chrome finished.

Item

No. Inch mm Inch Inch Inch Inch

3/32 60 2.4 6.1 .16 .16

7/64 60 2.4 6.1 .20 .20

1/8 60 2.4 6.1 .20 .20

9/64 60 2.4 6.1 .21 .24

5/32 60 2.4 6.1 .22 .24

3/16 60 2.4 6.1 .25 .28

7/32 60 2.4 6.7 .30 .32

1/4 60 2.4 6.7 .34 .36

*Metric dimensions actual - Inch dimensions approximate

Set 8 Pcs. Inch Nut Driver

Precision ESD Safe Dissipative

Handle Blade CVM steel, hardened, hard

chromed. In storage pouch

Item Inch Nut Drivers:

No. 3/32, 7/64, 1/8, 9/64, lbs.

5/32, 3/16, 7/32, 1/4” .68

Set 8 Pcs. Metric Nut Driver

Precision ESD Safe Dissipative Handle

Blade CVM steel, hardened, hard chromed.

Item Metric Nut Drivers:

No. 1.5, 2.0, 2.5, 3.0, lbs.

3.5, 4.0, 5.0, 5.5mm .63

ESD standard IEC 61340-5-1

Set 8 Pcs. Hex Metric Precision

ESD Safe Dissipative Handle Blade CVM

steel, hardened, hard chromed. Handle impact

resistant, dissipative material.

Item Hex Metric:

No. .7, .9, 1.3, 1.5, lbs.

2.0, 2.5, 3.0, 4.0mm .53

ESD standard IEC 61340-5-1

Wiha Precision ESD Safe Dissipative Nut Drivers

ESD standard IEC 61340-5-1

Surface resistance of handles is 106 - 109 Ohms

Storage

Pouch

lbs. pkg.

.02 10

.03 10

.04 10

.05 10

lbs. pkg.

.04 10

.05 10

.06 10

lbs. pkg.

.03 10

.04 10

.05 10

.06 10

.07 10

pkg.

10

27590

275 Metric

27507

27509

27513

27515

27520

27525

27530

27535

275 Inch

27505

27510

27513

27537

27539

27541

27543

27545

27547

27549

27590

27591

277

27701

27703

27705

27707

27709

27711

27713

27715

277

27720

27721

27722

27725

27730

27735

27740

27745

27750

27755

27760

27791

27790

Toll Free: (800) 494-6104

wihao Tools [hat work fol you 0 2. o———- 0 4m - - On 4mm Hex blades 0 O m A 0 9 O oo++n - 9- 9 o— o - - III 10 m :0 39 O O n oa=p IIIID g

7

Wiha SYSTEM 4 Drive-Loc Precision Locking Tools

ESD Safe Dissipative Precision

Drive-Loc Handle Surface resistant

106-109 Ohms. 4 mm hex retainer for all

SYSTEM 4 interchangeable blades. Ball

retainer hold. 105mm/4.13” OAL

Item

No. mm Inch mm Inch lbs.

4.0 .1574 23 .91 .08

D

SYSTEM 4 Slotted Drive-Loc

Reversible Locking Blades On 4mm Hex

Item

No. mm mm lbs.

1.5 + 3.0 .02

2.0 + 3.5 .02

2.5 + 4.0 .02

SYSTEM 4 Drive-Loc

Reversible Locking Blades On 4mm Hex

Item

No. Size Size lbs.

T1 + T2 .02

T3 + T4 .02

T5 + T6 .02

T6 + T8 .02

T7 + T9 .02

T10 + T15 .02

T15 + T20 .02

SYSTEM 4 Phillips Drive-Loc

Reversible Locking Blades On 4mm Hex

Item

No. Size Size lbs.

000 + 00 .02

0 + 1 .02

SYSTEM 4 Pozidriv® Drive-Loc

Reversible Locking Blades On 4mm Hex

Item

No. Size Size lbs.

0 + 1 .02

12 Piece SYSTEM 4 Precision

ESD Drive-Loc Set In storage pouch

Item No.

ESD Safe Drive-Loc Handle

Slotted: 1.5x3.0, 2.0x3.5, 2.5x4.0

lbs. .44 Phillips: 000x00, 0x1

: T1xT2, T3xT4, T5xT6,

T6xT8, T7xT9, T10xT15

SYSTEM 4 Metric Hex Drive-Loc

Reversible Locking Blades

On 4mm Hex blades

Item

No. mm mm lbs.

1.3 + 1.3 .02

1.5 + 1.5 .02

2.0 + 2.0 .02

2.5 + 2.5 .02

3.0 + 3.0 .02

4.0 + 4.0 .02

SYSTEM 4 Metric Nut Drivers

Drive-Loc Reversible Locking Blades

On 4mm Hex blades

Item

No. mm mm lbs.

1.5 + 1.8 .02

2.0 + 2.5 .02

3.0 + 3.0 .02

3.2 + 3.2 .02

3.5 + 3.5 .02

4.0 + 4.0 .02

4.5 + 4.5 .02

5.0 + 5.0 .02

5.5 + 5.5 .02

9 Piece ESD Safe Drive-Loc IV

Precision Blade Set In storage pouch

Item No.

ESD Safe Drive-Loc IV Handle

Slotted: 1.5x3.0, 2.0x3.5, 2.5x4.0

lbs. Phillips: 000x00, 0x1

.47 : T6xT8, T7xT9, T10xT15

12 Piece ESD Safe Drive-Loc IV

Precision Blade Set In storage pouch

Item No.

ESD Safe Drive-Loc IV Handle

Slotted: 2.0x3.5, 2.5x4.0

lbs. Phillips: 000x00, 0x1

.59 : T6xT8, T7xT9, T10xT15

AA SA Fine Point Tweezers

5 SA Extra Fine Point Tweezers

2a SA Flat & Blunt Tweezers

7a SA Curved & Fine Point Tweezers

Rugged Polyester Canvas

Storage Pouch Holds 8 Precision Tools up to

170mm in length. Folding pouch. Has security

flaps and velcro closer.

Item

No. Size lbs. pkg.

14-1/2” W x 7-3/4” L .13 1

Wiha Canvas Pouch

26961

269

26958

26959

26960

269

26975

26976

269

26977

26978

26979

26980

26981

26982

26983

28002

26985

280

28003

28004

28005

28006

28007

28008

280

28009

28010

28011

28012

28013

28014

28015

28016

28017

26994

26970

91118

www.wihatools.com

wihao Tools that work 10! you O— - Tapeved handle, high quahty plasuc. Impam - . “— COIL-Fm — oo++m 0W - a a 4.0 .1574 14.0 .55 .06 .. .=. 6 9 = __.. — " m— g o - G} . -Extenslon Blade For svs a Mlcro BI Shaft CVM s1eel, hardened. carrasuan proreored 0 relainev bit extensuon lor 4mm bus. - Q = I m m m = = m — a . 0 E;— mlbs. .06 2.5+4.0 120 4.7 .06 - 0 — .3 C) 0 .I" -, .3— - - Mlcro an 1/ " Drlve Power Tool - Adapter S Q=Om

8

Wiha SYSTEM 4 Precision

Bit Handle

Micro Bit 1/4” Drive Power Tool

Adapter Shaft CVM steel, hardened,

corrosion protected. For 4mm bits. 2.3” OAL

Item

No. Size mm mm lbs.

4.0 60 4.0 .07

Micro Bit 1/4” Drive Power

Tool Adapter

Extension Blade For SYS 4 Micro Bits

Shaft CVM steel, hardened, corrosion protected.

Ball retainer bit extension for 4mm bits.

Item

No. Size mm mm lbs.

4.0 100 4.0 .07

Magnetic Bit Extension Blade For

SYS 4 Micro Bits Shaft CVM steel, hardened,

corrosion protected. Magnetic bit holder.

Item

No. Size mm mm lbs.

4.0 100 4.0 .04

SYSTEM 4 Micro Bit

Extension Blades

D

SYSTEM 4 ESD Safe Dissipative

Precision Bit Handle 110mm/4.3” OAL

Advantages:

• For working in ESD sensitive applications

Surface resistant 106-109 Ohms

• Ball retainer holds bits securely in place

• Accepts all SYSTEM 4 Series bits

Item

No. mm Inch mm Inch lbs.

4.0 .1574 14.0 .55 .06

SYSTEM 4 Hex Inch Micro Bit

Replacement Pack, 10 Pcs.

CVM steel, hardened, on 4 mm hex stock.

Item No. SYSTEM 4 Micro Bit Set

Hex Inch: .028, .035, .050, 1/16,

5/64, 3/32, 7/64, 1/8, 9/64, 5/32”

lbs. .06

Wiha SYS 4 Micro Bit Packs

SYSTEM 4 Slotted Micro Bit

Replacement Pack, 10 Pcs.

CVM steel, hardened, on 4 mm hex stock.

Item No. SYSTEM 4 Micro Bit Set

Slotted: 0.8, 1.2, 1.5, 1.8, 2.0, 2.5,

3.0, 3.5, 4.0mm

lbs. .06

SYSTEM 4 Phillips & Pentalobe

Micro Bit Replacement Pack, 10 Pcs.

CVM steel, hardened, on 4 mm hex stock.

Item No. SYSTEM 4 Micro Bit Set

Phillips: #000, 00, 0, 1

Pentalobe: PL1, PL2, PL3,

PL4, PL5, PL6

lbs. .06

SYSTEM 4 Slotted & Phillips

Micro Bit Replacement Pack, 10 Pcs.

CVM steel, hardened, on 4 mm hex stock.

Item No. SYSTEM 4 Micro Bit Set

Slotted: 1.5, 2.0, 2.5, 3.0, 3.5mm

Phillips: #000, 00, 0, 1

lbs. .06

SYSTEM 4 Micro Bit

Replacement Pack, 10 Pcs.

CVM steel, hardened, on 4 mm hex stock.

Item No. SYSTEM 4 Micro Bit Set

: T1, T2, T3, T4, T5, T6,

T7, T8, T9, T10

lbs. .06

ESD Safe Dissipative Precision

Handle with rotating control cap. Surface

resistant 106-109 Ohms. 4 mm hex retainer

for all SYSTEM 4 interchangeable blades.

Tapered handle, high quality plastic, impact

resistant. Ball retainer hold. 110mm/4.3” OAL

Item

No. mm Inch mm Inch lbs.

4.0 .1574 14.0 .55 .04

SYSTEM 4 Phillips

Reversible Blade

Item

No. Size Size mm Inch lbs.

000 + 00 120 4.7 .03

0 + 1 120 4.7 .03

Wiha SYSTEM 4 Precision

Blade Handle

SYSTEM 4 Combined

Slotted/Phillips Reversible Blade

Item

No. mm Size mm Inch lbs.

1.5 + 000 120 4.7 .05

2.0 + 00 120 4.7 .05

3.0 + 0 120 4.7 .05

4.0 + 1 120 4.7 .06

SYSTEM 4 Slotted

Reversible Blade High alloy CVM steel,

hardened, hard chromed. Wiha vapor

Chrome-Top finish on tips.

Item

No. mm mm mm Inch lbs.

1.5 + 3.0 120 4.7 .05

2.0 + 3.5 120 4.7 .05

2.5 + 4.0 120 4.7 .06

SYSTEM 4 Pozidriv®

Reversible Blade High alloy CVM steel,

hardened, hard chromed. Wiha vapor

Chrome-Top finish on tips.

Item

No. Size Size mm Inch lbs.

0 + 1 120 4.7 .03

75801

75900

75901

75902

75801

75900

75901

75902

75982

75984

75982

75984

75986

75987

75988

28000

269

26903

26904

26905

269

26971

26972

26973

26974

269

26911

26912

26922

Toll Free: (800) 494-6104

wihao Tools lhal work 19' you 1oBitPacl‘< o="" m="" e="" a="=n" .="=n" 1obmpack="" 0="" a="" hhhih="" ._="" w="" ‘="" mlv="" m="" c—="" m‘="" '="" -="" -="" '="=“" 6="" m="" :0="=" n="" -="" a="=n" n="" hhvh="" m="" 4,0="" 28="" 1.l="" .05="" o-="" o="=" m="" a="" a="" mumn="" “h,"="" w="" o'-="" m="" fem="" a="=m" -="" o="=" n="" 0="" m="" o="" w="" o="=ﬁ" -="" -="" 0="=n" ilem="" 0="=n">

9

Wiha SYSTEM 4 Micro Bits - 10 Bit Packs

SYSTEM 4 Metric Nut Setters

Item No.

Metric mm mm Inch lbs.

2.0 30 1.2 .07

2.5 30 1.2 .07

3.0 30 1.2 .07

3.5 30 1.2 .07

4.0 30 1.2 .08

4.5 30 1.2 .08

5.0 30 1.2 .08

5.5 30 1.2 .09

SYSTEM 4 Pentalobe Micro Bits

Item

No. Size mm Inch lbs.

PL1 28 1.1 .06

PL2 28 1.1 .06

PL3 28 1.1 .07

PL4 28 1.1 .07

PL5 28 1.1 .07

PL6 28 1.1 .08

SYSTEM 4 Inch Nut Setters

Item No.

Inch mm mm Inch lbs.

5/64 30 1.2 .07

3/32 30 1.2 .07

7/64 30 1.2 .07

1/8 30 1.2 .07

9/64 30 1.2 .08

5/32 30 1.2 .08

3/16 30 1.2 .08

7/32 30 1.2 .09

10 Bit Pack

Use bits directly in handle or

with 4” bit extension

Bits High alloy

CVM steel,

hardened

Tips Exact fit,

precision machined

Micro Bits Made in Germany

SYSTEM 4 Slotted Micro Bits

Item

No. mm mm Inch lbs.

0.8 28 1.1 .06

1.2 28 1.1 .06

1.5 28 1.1 .06

1.8 28 1.1 .06

2.0 28 1.1 .07

2.5 28 1.1 .07

3.0 28 1.1 .07

3.5 28 1.1 .07

4.0 28 1.1 .08

10 Bit Pack

SYSTEM 4 Phillips Micro Bits

Item

No. Size mm Inch lbs.

000 28 1.1 .06

00 28 1.1 .06

0 28 1.1 .06

1 28 1.1 .07

2 28 1.1 .07

SYSTEM 4 Hex Metric Micro Bits

Item

No. mm mm Inch lbs.

.7 28 1.1 .06

.9 28 1.1 .06

1.3 28 1.1 .06

1.5 28 1.1 .07

2.0 28 1.1 .07

2.5 28 1.1 .07

3.0 28 1.1 .08

4.0 28 1.1 .08

SYSTEM 4 Hex Inch Micro Bits

Item

No. Inch mm Inch lbs.

.028 28 1.1 .06

.035 28 1.1 .06

.050 28 1.1 .06

1/16 28 1.1 .06

5/64 28 1.1 .06

3/32 28 1.1 .07

7/64 28 1.1 .07

1/8 28 1.1 .07

9/64 28 1.1 .08

5/32 28 1.1 .08

10 Bit Pack

SYS 4 Security Micro Bits

Item

No. Size mm Inch lbs.

T10s 28 1.1 .07

T20s 28 1.1 .08

SYS 4 Metric Security Hex Micro Bits

Item

No. mm mm Inch lbs.

2.0 28 1.1 .06

3.0 28 1.1 .07

4.0 28 1.1 .08

SYS 4 Security Hex Inch Micro Bits

Item

No. Inch mm Inch lbs.

5/64 28 1.1 .06

3/32 28 1.1 .06

7/64 28 1.1 .07

1/8 28 1.1 .07

9/64 28 1.1 .08

5/32 28 1.1 .08

10 Bit Pack

SYSTEM 4 Micro Bits

Item

No. Size mm Inch lbs.

T1 28 1.1 .06

T2 28 1.1 .06

T3 28 1.1 .06

T4 28 1.1 .06

T5 28 1.1 .06

T6 28 1.1 .06

T7 28 1.1 .06

T8 28 1.1 .07

T9 28 1.1 .07

T10 28 1.1 .07

T15 28 1.1 .08

T20 28 1.1 .08

CVM steel, hardened,

on 4 mm hex stock.

10 Bit Pack

756

75602

75603

75604

75605

75606

75607

75608

75609

75610

75611

75612

75613

75614

75615

75672

75673

75674

75675

75676

75677

75616

75617

75618

75619

75620

75621

75622

75623

75628

75629

75630

75631

75632

75633

75634

75635

75636

75637

75624

75626

75627

75638

75639

75640

75641

75642

75643

75652

75653

75654

75655

75656

75657

75658

75659

75644

75645

75646

75647

75648

75649

75650

75651

75681

75683

75660

75661

75662

75663

75664

75665

75666

75667

75668

75669

75670

75671

756

756 756

756

www.wihatools.com

wihao 1 0 Tools that work 10! you SYSTEM 4 Handles & Micro Bits Blls CVM steel, hardened Use bms mmclly m handle or with 4"bmex1ension II 3 ea - SVSTEM 4 Phllllps ans 9==m -SVS CVMsleel. Item . = = N No. m 1 1 2 2 a 4.0 28 m .01

10

SYSTEM 4 Slotted Bits High alloy

CVM steel, hardened, on 4 mm hex stock.

Item

No. mm mm Inch lbs.

0.8 28 1.1 .01

1.2 28 1.1 .01

1.5 28 1.1 .01

1.8 28 1.1 .01

2.0 28 1.1 .01

2.5 28 1.1 .01

3.0 28 1.1 .01

3.5 28 1.1 .01

4.0 28 1.1 .01

SYSTEM 4 Phillips Bits

High alloy chrome-vanadium-molybdenum

steel, hardened, on 4 mm hex stock.

Item

No. Size mm Inch lbs.

000 28 1.1 .01

00 28 1.1 .01

0 28 1.1 .01

1 28 1.1 .01

2 28 1.1 .01

SYSTEM 4 Hex Metric Bits High alloy

CVM steel, hardened, on 4 mm hex stock.

Item

No. mm mm Inch lbs.

.7 28 1.1 .01

.9 28 1.1 .01

1.3 28 1.1 .01

1.5 28 1.1 .01

2.0 28 1.1 .01

2.5 28 1.1 .01

3.0 28 1.1 .01

4.0 28 1.1 .01

SYSTEM 4 Hex Inch Bits High alloy

CVM steel, hardened, on 4 mm hex stock.

Item

No. Inch mm Inch lbs.

.028 28 1.1 .01

.035 28 1.1 .01

.050 28 1.1 .01

1/16 28 1.1 .01

5/64 28 1.1 .01

3/32 28 1.1 .01

7/64 28 1.1 .01

1/8 28 1.1 .01

9/64 28 1.1 .01

5/32 28 1.1 .01

SYSTEM 4 Bits

High alloy chrome-vanadium-molybdenum

steel, hardened, on 4 mm stock.

Item

No. Size mm Inch lbs.

T1 28 1.1 .01

T2 28 1.1 .01

T3 28 1.1 .01

T4 28 1.1 .01

T5 28 1.1 .01

T6 28 1.1 .01

T7 28 1.1 .01

T8 28 1.1 .01

T9 28 1.1 .01

T10 28 1.1 .01

T15 28 1.1 .01

T20 28 1.1 .01

SYSTEM 4 Security Bits

High alloy CVM steel, hardened,

on 4 mm stock.

Item

No. Size mm Inch lbs.

T10s 28 1.1 .01

T20s 28 1.1 .01

SYSTEM 4 Metric Security Hex Bits

High alloy CVM steel, hardened,

on 4 mm hex stock.

Item

No. mm mm Inch lbs.

2.0 28 1.1 .01

3.0 28 1.1 .01

4.0 28 1.1 .01

SYSTEM 4 Security Hex Inch Bits

High alloy CVM steel, hardened,

on 4 mm hex stock.

Item

No. Inch mm Inch lbs.

5/64 28 1.1 .01

3/32 28 1.1 .01

7/64 28 1.1 .01

1/8 28 1.1 .01

9/64 28 1.1 .01

5/32 28 1.1 .01

Use bits directly in handle or with 4” bit extension

Bits CVM steel, hardened

SYSTEM 4

Handles &

Micro Bits

Tapered Handle

allows rapid rotation,

requires less clearance.

Static Dissipative

106 - 109 ohms

Rotating Cap

for precise

turning & control

Tips

Exact fit,

precision

machined

SYSTEM 4 Pentalobe Micro Bits

CVM steel, hardened, on 4 mm hex stock.

Item

No. Size mm Inch lbs.

PL1 28 1.1 .01

PL2 28 1.1 .01

PL3 28 1.1 .01

PL4 28 1.1 .01

PL5 28 1.1 .01

PL6 28 1.1 .01

SYSTEM 4 Metric & Inch Nut Setters

CVM steel, hardened, on 4 mm hex stock.

Item No.

Metric mm mm Inch lbs.

2.0 30 1.2 .01

2.5 30 1.2 .01

3.0 30 1.2 .01

3.5 30 1.2 .01

4.0 30 1.2 .01

4.5 30 1.2 .01

5.0 30 1.2 .01

5.5 30 1.2 .01

Inch Inch mm Inch lbs.

5/64 30 1.2 .01

3/32 30 1.2 .01

7/64 30 1.2 .01

1/8 30 1.2 .01

9/64 30 1.2 .01

5/32 30 1.2 .01

3/16 30 1.2 .01

7/32 30 1.2 .01

750

75008

75012

75015

75018

75020

75025

75030

75035

75040

751

75105

75110

75115

75120

75125

753

75307

75309

75313

75315

75320

75325

75330

75340

753

75307

75309

75313

75350

75352

75354

75356

75358

75360

75340

757

75701

75702

75703

75704

75705

75706

75707

75708

75709

75710

75715

75720

753

75322

75332

75342

753

75362

75364

75366

75368

75370

75372

753

75735

75742

757

75743

75744

75745

75746

75747

75748

758

75820

75821

75822

75823

75824

75825

75826

75827

75810

75811

75812

75813

75814

75815

75816

75817

Toll Free: (800) 494-6104

wihao Tools [hat work fol you A: D - SVSTEM 4 Mlnl Metal Box Mlcro an Set, 39 Pcs. Includes tha ESD Sale Precismn m (0 n III 9 O m {3 o m 0 C C 0 0 O O "mam 4 3131 - SVSTEM 4 Master Tech Mlcro an Set, 65 Pcs. Includes Wiha ESD Sale Precusmn °m°m ﬂ m 10 m '0 gm {3 cm : 0 o . O O O “ﬂ“M ﬂ 7i°1 "WM 3531 Om O 10

11

D

Wiha SYSTEM 4 ESD Safe Compact Micro Bit Sets

SYSTEM 4 Master Tech Micro Bit

Set, 68 Pcs. Includes Wiha ESD Safe Precision

Handle, Micro Bit Storage Handle, 1/4” to 4mm

Adapter, 100mm Bit Extension & 64 Micro Bits.

Item No. SYSTEM 4 Micro Bit Set

Includes:

Slotted: 0.8, 1.2, 1.5,

lbs. 1.8, 2.0, 2.5, 3.0, 3.5, 4.0mm

.70 Phillips: 000, 00, 0, 1, 2

: T1, T2, T3, T4, T5,

T6, T7, T8, T9, T10, T15, T20

Hex Metric: 1.3, 1.5, 2.0, 2.5, 3.0, 4.0mm

Hex Inch: .028, .035, .050, 1/16,

5/64, 3/32, 7/64, 1/8, 9/64, 5/32”

Pentalobe: PL1, PL2, PL3, PL4, PL5, PL6

Nut Driver Metric: 2.0, 2.5, 3.0, 3.5,

4.0, 4.5, 5.0, 5.5mm

Nut Driver Inch: 5/64, 3/32, 7/64,

1/8, 9/64, 5/32, 3/16, 7/32”

D

Includes

Dust Cover

SYSTEM 4 Master Tech Micro Bit

Set, 68 Pcs. Includes Wiha ESD Safe Precision

Handle, Micro Bit Storage Handle, 1/4” to 4mm

Adapter, 100mm Bit Extension & 64 Micro Bits.

Item No. SYSTEM 4 Micro Bit Set

Includes:

Slotted: 0.8, 1.2, 1.5,

lbs. 1.8, 2.0, 2.5, 3.0, 3.5, 4.0mm

.96 Phillips: 000, 00, 0, 1, 2

: T1, T2, T3, T4, T5,

T6, T7, T8, T9, T10, T15, T20

Hex Metric: 1.3, 1.5, 2.0, 2.5, 3.0, 4.0mm

Hex Inch: .028, .035, .050, 1/16,

5/64, 3/32, 7/64, 1/8, 9/64, 5/32”

Pentalobe: PL1, PL2, PL3, PL4, PL5, PL6

Nut Driver Metric: 2.0, 2.5, 3.0, 3.5,

4.0, 4.5, 5.0, 5.5mm

Nut Driver Inch: 5/64, 3/32, 7/64,

1/8, 9/64, 5/32, 3/16, 7/32”

D

In Zipper

Storage Case

SYSTEM 4 Interchangeable Bit Set,

40 Pcs. Includes Wiha precision handle,

bit extension & 38 interchangeable bits.

Item SYSTEM 4

No. Combination Bit Set

Set with ESD Safe Precision Handle

Set includes the following bits:

lbs. Slotted: 0.8, 1.2, 1.5,

1.04 1.8, 2.0, 2.5, 3.0, 3.5, 4.0mm

Phillips: 000, 00, 0, 1

: T3, T4, T5,

T6, T7, T8, T9, T10, T15

Hex Metric: 1.3, 1.5,

2.0, 2.5, 3.0, 4.0mm

Hex Inch: .028, .035, .050, 1/16,

5/64, 3/32, 7/64, 1/8, 9/64, 5/32”

100mm Bit Extension

40 Pc. Set

In Metal

Storage Box Wiha SYSTEM 4 Compact

Micro Bit Sets

SYS 4 Precision Interchangeable Bit

Set, 26 Pcs. In Compact Fold Out Box

Sets includes Wiha precision handle, bit

extension & 24 Wiha interchangeable bits.

Item SYSTEM 4 Micro Bit Set

No. Set with ESD Safe Precision Handle

and the following bits:

: T1, T2, T3, T4, T5, T6, T7,

T8, T9, T10

Pentalobe: PL1, PL2, PL3, PL4, PL5, PL6

Slotted: 1.5, 2.0, 2.5, 3.0mm

Phillips: #000, 00, 0, 1

100mm Bit Extension

lbs. .54

26 Pc. Set

D

SYSTEM 4 Master Tech Micro Bit

Set, 68 Pcs. Includes Wiha ESD Safe Precision

Handle, ESD Safe Tweezers, 1/4” to 4mm

Adapter, 100mm Bit Extension & 64 Micro Bits.

Item No. SYSTEM 4 Micro Bit Set

Includes The Following Bits:

Slotted: 0.8, 1.2, 1.5,

lbs. 1.8, 2.0, 2.5, 3.0, 3.5, 4.0mm

1.00 Phillips: 000, 00, 0, 1, 2

: T1, T2, T3, T4, T5,

T6, T7, T8, T9, T10, T15, T20

Hex Metric: 1.3, 1.5, 2.0, 2.5, 3.0, 4.0mm

Hex Inch: .028, .035, .050, 1/16,

5/64, 3/32, 7/64, 1/8, 9/64, 5/32”

PL1, PL2, PL3, PL4, PL5, PL6

Nut Driver Metric: 2.0, 2.5, 3.0, 3.5,

4.0, 4.5, 5.0, 5.5mm

Nut Driver Inch: 5/64, 3/32, 7/64,

1/8, 9/64, 5/32, 3/16, 7/32”

ESD Fine Round Point Tweezers 3cSA

D

In Zipper Storage Case

SYSTEM 4 Mini Metal Box Micro Bit

Set, 39 Pcs. Includes Wiha ESD Safe Precision

Handle, 1/4” to 4mm Adapter, 100mm Bit

Extension & 36 Micro Bits.

Item No. SYSTEM 4 Micro Bit Set

Includes:

Slotted: 0.8, 1.2, 1.5,

lbs. 1.8, 2.0, 2.5, 3.0, 3.5, 4.0mm

.40 Phillips: 000, 00, 0, 1, 2

: T1, T2, T3, T4, T5,

T6, T7, T8, T9, T10

Hex Metric: 1.3, 1.5, 2.0, 2.5, 3.0, 4.0mm

Pentalobe: PL1, PL2, PL3, PL4, PL5, PL6

75996

75968

75971

75996

75971

75968

75995

75977

75980

www.wihatools.com

wihao Tools that work 10! you 0 0 m9 Owner :1. 40— O 09. 111 «ram - - 0 9 {I n O W 6 O O 0 Set, 27 Pcs. In Compacl Fold om Box. Se‘s 0 9 O 10 mt enensmn an 14 inlemhangeame bits. 6 O 1'0lee I0 0 9 m . O m .17 0 100mm Bll Exlenslon

12

SYSTEM 4 Slotted/Phillips/Hex

Inch/ Precision Interchangeable Bit

Set, 27 Pcs. In Compact Fold Out Box. Sets

include your choice of Wiha precision handle,

bit extension & 25 Wiha interchangeable bits.

Item Handle Options for SYSTEM 4

No. Combination Bit Sets

Set with Standard Precision Handle

Set with ESD Safe Precision Handle

Sets include the following bits:

Slotted: 1.5, 2.0, 3.0, 4.0mm

Phillips: 000, 00, 0, 1

: T3, T4, T5,

T6, T7, T8, T9, T10, T15

Hex Inch: .050, 1/16, 5/64,

3/32, 7/64, 1/8, 9/64, 5/32”

100mm Bit Extension

lbs. .64

27 Pc. Set

SYSTEM 4 Slotted/Phillips/Hex

Metric/ Precision Interchangeable Bit

Set, 27 Pcs. In Compact Fold Out Box.

Set includes Wiha precision handle, bit

extension and 25 Wiha interchangeable bits.

Item SYSTEM 4

No. Combination Bit Set

Set with ESD Safe Precision Handle

Set includes the following bits:

Slotted: 1.5, 2.0, 3.0, 4.0mm

Phillips: 000, 00, 0, 1

:

T3, T4, T5, T6, T7, T8, T9, T10, T15

Hex Metric: .7, .9, 1.3,

1.5, 2.0, 2.5, 3.0, 4.0mm

100mm Bit Extension

lbs. .64

27 Pc. Set

D

SYS 4 Slotted, Phillips, Hex Inch

Compact ESD Precision Interchangeable

Bit Set, 16 Pcs. Wiha precision handle,

bit extension & 14 interchangeable bits.

Item No. Combination Bit Set

Set with ESD Safe Precision Handle

Slotted: 1.5, 2.0, 2.5, 3.0mm

Phillips: 00, 0, 1

Hex Inch: .035, .050, 1/16, 5/64,

lbs. 3/32, 7/64, 1/8”

.17 100mm Bit Extension

SYSTEM 4 Slotted, Phillips,

Compact ESD Precision Interchangeable

Bit Set, 16 Pcs. Wiha precision handle,

bit extension & 14 interchangeable bits.

Item No. Combination Bit Set

Set with ESD Safe Precision Handle

Slotted: 1.5, 2.0, 2.5, 3.0mm

Phillips: 00, 0, 1

lbs. : T6, T7, T8, T9, T10, T15, T20

.17 100mm Bit Extension

SYS 4 Slotted, Phillips, Hex Metric

Compact ESD Precision Interchangeable

Bit Set, 16 Pcs. Wiha precision handle,

bit extension & 14 interchangeable bits.

Item No. Combination Bit Set

Set with ESD Safe Precision Handle

Slotted: 1.5, 2.0, 2.5, 3.0mm

Phillips: 00, 0, 1

Hex Metric: .9, 1.3, 1.5, 2.0,

lbs. 2.5, 3.0, 4.0mm

.17 100mm Bit Extension

Bits hardened for

extreme durability

Handle tapered for

precise control

Light weight &

compact

Technician’s MicroBit Sets

• Micro Precision Bits on 4mm Hex Drive

• Bits of Exclusive CRM-72 Tool Steel

• Handle uses non-magnetic ball retainer

• Use bits in extension only

• Standard extension adds 4” to length

• Non-magnetic bit extension

Rotation cap

Surface resistance of

handles is 106 - 109 Ohms

SYSTEM 4 Hex Inch & Metric

Compact ESD Precision Interchangeable

Bit Set, 16 Pcs. Wiha precision handle,

bit extension & 14 interchangeable bits.

Item No. Combination Bit Set

Set with ESD Safe Precision Handle

Hex Inch: 1/16, 5/64, 3/32,

7/64, 1/8, 9/64, 5/32”

Hex Metric: .9, 1.3, 1.5, 2.0,

lbs. 2.5, 3.0, 4.0mm

.17 100mm Bit Extension

D

SYS 4 Slotted, Phillips & 5Point

Compact ESD Precision Interchangeable

Bit Set, 16 Pcs. Wiha precision handle,

bit extension & 14 interchangeable bits.

Item No. Combination Bit Set

Set with ESD Safe Precision Handle

Slotted: 1.2, 1.5, 2.0, 2.5, 3.0mm

Phillips: 000, 00, 0, 1, 2

lbs. Pentalobe: PL1, PL2, PL3, PL4

.17 100mm Bit Extension

Wiha SYSTEM 4 Compact

Micro Bit Set

75093

75094

75095

75096

75097

759

75991

75992

75994

75994 75093 75096

75094

75097

75095

Toll Free: (800) 494-6104

wihao 00. -\ '4 Tools that work 10! you DIN 3126, ISO 1173 Stainless steel wim relalmng nng bil holder. multircompcnem‘ ESD Sale sunace 02:3?“- Release Blade Holder Extenslon m & “F For working m sensitive electronic componems Conduclive‘ AnIi-slalic, Dwssipative \‘é\ - -ﬁ

13

ESD Safe Cushion Grip Bit Holders

ESD Safe Stubby 1/4” Bit Holder

With Ring Retainer, Wiha-SoftFinish®

Cushion Grip Handle, IEC 61340-5-1,

DIN 3126, ISO 1173 Dissipative SoftFinish®

cushion grip handle, multi-component,

ESD Safe surface resistance 106 - 109 Ohm.

Item

No. Inch mm Inch lbs. pkg.

1/4” 57 2.2 .11 1

ESD Safe Quick Release 1/4” Bit

Holder, With Wiha-SoftFinish® Cushion Grip

Handle, IEC 61340-5-1, DIN 3126, ISO 1173

Stainless steel with retaining ring bit holder.

Dissipative SoftFinish® cushion grip handle,

multi-component, ESD Safe surface

resistance 106 - 109 Ohm.

Item

No. Inch mm Inch mm Inch lbs. pkg.

1/4” 148 5.8 38 1.5 .24 1

Surface resistance of handles is 106 - 109 Ohms

For working on static

sensitive components

Dissipative material offers protection

against electrostatic discharge

ESD Safe 1/4” Quick Release

Blade Holder Set 20 Pc. Set With

Interchangeable Blades & Quick

Release Blade Holder Extension

Blades are CVM tool steel, hardened.

Item No. lbs. .67

Slotted: 2.5, 3.0, 3.5, 4.0, 5.5, 6.5mm

Phillips: 0, 1, 2

TORX®: T6, T7, T8, T9, T10, T15

Pozidriv®: 0, 1, 2

In Durable

Pouch

Surface

resistance

of handle is

106 - 109

Ohms

Bit holders

without magnetics

D

ESD

Safe

For working in sensitive

electronic components

Conductive, Anti-static,

Dissipative

ESD Standard

IEC 61340-5-1

Item

No. Reading mm Inch Pkg. wt.

.001” 150 6 Inch 1 .10

0.1mm 150 6 Metric 1 .10

ESD Safe Dial Caliper DialMax -

Metric & Inch Non-metallic high-tech material

with 60% fiber glass content. For outside,

inside, depth & step measurements. Impact

resistant dial can be recalibrated to zero.

ESD Safe Dial Caliper DialMax

Metric & Inch

Precision ratchet guarantees

uniform clamping force of the

measuring jaw

Won’t damage

sensitive parts

Non-metallic high-tech material with 60%

fiber glass content, extremely high rigidity.

Non-corrosive,

non-magnetic,

hardly conductive &

electrically insulated

Thermal stability of the

measuring surfaces:

Short-term up to

180OC, continuous

100-120OC

Inside Outside

Depth Step

Made in

Switzerland

Surface resistance

of handle is 106 - 109 Ohms

D

SYSTEM 4 Master Tech ESD &

Ratchet With Micro Bits, 65 Pieces In

Storage Box. Includes Wiha precision ESD

Safe handle, micro bit extension, 72 tooth 1/4”

ratchet & 62 interchangeable micro bits.

Item Includes:

No. Slotted: 0.8, 1.2, 1.5, 1.8,

2.0, 2.5, 3.0, 3.5, 4.0mm

Phillips: 000, 00, 0, 1

lbs. : T3, T4, T5, T6, T7, T8,

1.16 T9, T10, T15, T20

Hex Metric: .7, .9, 1.3, 1.5, 2.0,

2.5, 3.0, 4.0mm

Hex Inch: .050, 1/16, 5/64,

3/32, 7/64, 1/8, 9/64, 5/32”

Nut Drivers Metric: 2.0, 2.5, 3.0,

3.5, 4.0, 4.5, 5.0, 5.5mm

Nut Drivers Inch: 5/64, 3/32,

7/64, 1/8, 9/64, 5/32, 3/16, 7/32”

Pentalobe: PL1, PL2, PL3, PL4, PL5, PL6

Magnetic 1/4” to 4mm Adapter

D

ESD Safe Cushion Grip Bit Holders

38701

38790

28180

38790

38701

28180

411

41105

41106

75965

www.wihatools.com

.h Tools [hat work for you I‘ I- t' .v III 10 =- ‘i ii ii I} l For working on static sensitive components Dissipative materiai offers protection against eiectrostatic discharge SoftFinish cushion grip handle CVM steei hardened, hard chrome Finish DIN EN 51340-51I5134w5-2 I0 9 1i 1i ii ii I} I I. 10 '0 o =-=-1010 ii ii I} I grip handler multircamponent, ESD Sate no 710 Ohm). r“;

14

DIN EN 61340-5-1/ 61340-5-2

SoftFinish

cushion grip

handle

CVM steel hardened,

hard chrome Finish

For working on static

sensitive components

Dissipative material

offers protection

against electrostatic

discharge

Wiha ESD Safe SoftFinish Cushion Grip Screwdrivers

ESD Safe Slotted Screwdrivers, With Wiha-SoftFinish® Handle

DIN EN 61340-5-1/61340-5-2 Round blade, high alloy CVM steel, hardened, hard chromed.

Offers protection against electrostatic discharge. Dissipative SoftFinish® cushion grip handle,

multi-component, ESD Safe (106-109 Ohm).

Item

No. mm Inch mm Inch mm Inch mm Inch lbs. pkg.

2.5 .098 75 3.0 0.4 .016 175 7.0 .06 10

3.0 .118 100 3.9 0.5 .020 204 8.0 .06 10

4.0 .157 100 3.9 0.8 .031 211 8.3 .11 10

5.5 .216 125 5.0 1.0 .039 236 9.3 .15 10

6.5 .255 150 5.9 1.2 .047 268 10.6 .22 10

*Cabinet Tips

ESD Safe Phillips Screwdriver, With Wiha-SoftFinish® Handle

DIN EN 61340-5-1/61340-5-2 Round blade, high alloy CVM steel, hardened, hard chromed.

Offers protection against electrostatic discharge. Dissipative SoftFinish® cushion grip handle,

multi-component, ESD Safe (106-109 Ohm).

Item

No. Size mm Inch mm Inch mm Inch lbs. pkg.

0 60 2.4 3.0 1/8 164 6.5 .06 10

1 80 3.1 4.5 3/16 191 7.5 .11 10

2 100 3.9 6.0 1/4 218 8.6 .20 10

ESD Safe Screwdriver, With Wiha-SoftFinish® Handle

DIN EN 61340-5-1/61340-5-2 Round blade, high alloy CVM steel, hardened, hard chromed.

Offers protection against electrostatic discharge. Dissipative SoftFinish® cushion grip handle,

multi-component, ESD Safe (106-109 Ohm).

Item

No. Size mm Inch mm Inch mm Inch lbs. pkg.

T3 60 2.4 3.5 .139 164 6.5 .06 10

T4 60 2.4 3.5 .139 164 6.5 .06 10

T5 60 2.4 3.5 .139 164 6.5 .06 10

T6 60 2.4 3.5 .139 164 6.5 .06 10

T8 60 2.4 3.5 .139 164 6.5 .06 10

T9 60 2.4 4.0 .157 171 6.7 .10 10

T10 80 3.1 4.0 .157 191 7.5 .11 10

T15 80 3.1 4.0 .157 191 7.5 .11 10

T20 100 3.9 4.0 .157 211 8.3 .11 10

Set 6 Pcs. ESD Safe Slotted

& Phillips DIN EN 61340-5-1/61340-5-2

Round blade, high alloy CVM steel, hardened,

hard chromed. Dissipative SoftFinish® cushion

grip handle, multi-component, ESD Safe

(106-109 Ohm).

Item Slotted:

No. *3.0, *4.0, *5.5mm lbs.

Phillips: 0, 1, 2 .96

*Cabinet Tips

Set 6 Pcs. ESD Safe

Screwdrivers Round blade high alloy CVM

steel, hardened, Hard chrome finish with Wiha-

Chromtop satin grip tips. Molded on SoftFinish®

cushion grip handle, multi-component.

Item

No. T6, T8, T9, lbs.

T10, T15, T20 .81

D

ESD Safe

D

Wiha ESD Safe SoftFinish®

302

30240*

30242*

30244*

30246*

30248

311

31150

31151

31152

30292

362

36260

36204

36200

36206

36208

36209

36218

36219

36224

36289

Toll Free: (800) 494-6104

wihao Tools that work 10! you Locking m cushion 9 Blade le lmm 1,7 For Adiusiable Length Locking Blades ® B‘a 5m Dnve-Loc mechamsm @ @ W - guarantees a secure ham 5. mm mane exchange 4 5 10 1 exchange 51am Dissipative. O==++m 09n— ®®ﬁ— 6.0 2 .10 1 99m— 00m—

15

ESD Safe Drive-Loc VI Cushion

Grip Handle Wiha-SoftFinish® impact resis-

tant, with roll off protection. Advantages:

Ergonomic cushion grip, Drive-Loc mechanism

guarantees a secure hold and rapid blade

exchange. Static Dissipative.

Item

No. mm mm Inch mm Inch lbs.

6.0 115 4.5 36.0 1.41 .21

D

Slotted Drive-Loc VI Interchangeable

Blade High alloy CVM steel, through hardened,

hard chrome finish. OAL 150mm/5.9”.

Blades fit all Drive-Loc VI handles.

Item

No. mm + mm lbs. pkg.

3.5 4.5 .10 1

5.5 6.5 .10 1

Slotted & Phillips Drive-Loc VI

Interchangeable Blade High alloy CVM steel,

through hardened, hard chrome finish. OAL

150mm/5.9”. Blades fit all Drive-Loc VI handles.

Item

No. mm + Size lbs. pkg.

3.0 0 .10 1

4.0 1 .10 1

6.0 2 .10 1

Phillips Drive-Loc VI Interchangeable

Blade High alloy CVM steel, through hardened,

hard chrome finish. OAL 150mm/5.9”. Blades fit

all Drive-Loc VI handles.

Item

No. Size + Size lbs. pkg.

1 2 .10 1

Square Drive-Loc VI Interchangeable

Blade High alloy CVM steel, through hardened,

hard chrome finish. OAL 150mm/5.9”. Blades fit

all Drive-Loc VI handles.

Item

No. Size + Size lbs. pkg.

1 2 .10 1

Tri-wing® Drive-Loc VI Interchangeable

Blade High alloy CVM steel, through hardened,

hard chrome finish. OAL 150mm/5.9”. Blades

fit all Drive-Loc VI handles.

Item

No. Size + Size lbs. pkg.

0 1 .10 1

2 3 .10 1

4 5 .10 1

Pozidriv® Drive-Loc VI Interchangeable

Blade High alloy CVM steel, through hardened,

hard chrome finish. OAL 150mm/5.9”. Blades fit

all Drive-Loc VI handles.

Item

No. Size + Size lbs. pkg.

1 2 .10 1

Blades high quality CVM

steel, hard chrome finish

Adjust

interchangeable

blades from

40 to 120mm

Drive-Loc mechanism

guarantees a secure hold &

rapid blade exchange

For Adjustable Length

Locking Blades

Locking mechanism in SoftFinish

cushion grip ergonomic handle.

Blade length can be adjusted

from 1.7 to 4.7” In 1/8” increments

Ergonomic

handles in ESD

Safe, cushioned

& non-slip grip

Drive-Loc VI Interchangeable

Blade OAL 150mm/5.9”

Item

No. Size + Size lbs. pkg.

T6 T8 .10 1

T7 T9 .10 1

T10 T15 .10 1

T20 T25 .10 1

T30 T40 .10 1

Security Drive-Loc VI

Interchangeable Blade OAL 150mm/5.9”

Item

No. Size + Size lbs. pkg.

T6s T8s .10 1

T7s T9s .10 1

T10s T15s .10 1

T20s T25s .10 1

T30s T40s .10 1

Torq Set® Drive-Loc VI Interchangeable

Blade High alloy CVM steel, through hardened,

hard chrome finish. OAL 150mm/5.9”. Blades fit

all Drive-Loc VI handles.

Item

No. Size + Size lbs. pkg.

2 4 .08 1

6 8 .10 1

28486

281

28106

28108

28107

28109

28110

28112 28114

28137

28114

28112

28486

28126

28127

28128

28129

28130

28132

28133

28134

28135

28136

28138

28139

28140

28142

28143

www.wihatools.com

wihao Tools [hat work fol you n W,” A Q . O- H” ”‘9 - O =ﬁ- ’7/ O ..n- - :1 .0m- “m H H HIIIH” . H mm uuum hand‘e & 10 inlemhangeab‘e blades m

16

Wiha Drive-Loc VI Blades

Ball End Hex & Hex Metric Drive-Loc VI

Interchangeable Blade Ball end enables

the user to work at angles up to 25O. OAL

150mm/5.9”. Fits all Drive-Loc VI handles.

Item

No. mm + mm lbs. pkg.

2.5 2.5 .10 1

3 3 .10 1

4 4 .10 1

5 5 .10 1

6 6 .10 1

Hex Metric Drive-Loc VI Interchangeable

Blade OAL 150mm/5.9”

Item

No. mm + mm lbs. pkg.

2.0 2.5 .09 1

3.0 4.0 .10 1

5.0 6.0 .10 1

Hex Inch Drive-Loc VI Interchangeable

Blade OAL 150mm/5.9”

Item

No. Inch + Inch lbs. pkg.

3/32 7/64 .10 1

1/8 9/64 .10 1

5/32 3/16 .10 1

D

32 Pc. ESD Safe Drive-Loc VI

Interchangeable Blade Set, In Canvas

Pouch Set includes Drive-Loc VI handle & 31

interchangeable blades.

Item No. lbs. 3.66

Slotted: 3.5+4.5, 5.5+6.5mm Square: 1+2

Slotted/Phillips: 3.0+0, 4.0+1, 6.0+2

Security : T6s+T8s, T7s+T9s, T10s+T15s,

T20s+T25s, T30s+T40s

Hex Inch: 3/32+7/64, 1/8+9/64, 5/32+3/16

Hex Metric: 2.0+2.5, 3.0+4.0, 5.0+6.0

Nut Drivers In: 1/4, 9/32, 5/16, 11/32, 3/8, 7/16, 1/2”

Nut Drivers MM: 5.5, 6.0, 7.0, 8.0, 9.0, 10.0, 11.0mm

Wiha ESD Safe SoftFinish® Cushion Grip

Drive-Loc VI Inch Nut Driver Blades

High alloy CVM steel, through hardened, hard

chrome finish. OAL blade length 150mm/5.9”.

Blades fit all Drive-Loc VI handles.

Item

No. Inch OAL lbs. pkg.

3/16 5.9” .11 1

7/32 5.9” .11 1

1/4 5.9” .11 1

9/32 5.9” .12 1

5/16 5.9” .13 1

11/32 5.9” .14 1

3/8 5.9” .15 1

7/16 5.9” .17 1

1/2 5.9” .18 1

Drive-Loc VI Metric Nut Driver Blades

Blades fit all Drive-Loc VI handles

Item

No. mm OAL lbs. pkg.

4.0 150mm .10 1

4.5 150mm .10 1

5.0 150mm .11 1

5.5 150mm .11 1

6.0 150mm .12 1

7.0 150mm .13 1

8.0 150mm .13 1

9.0 150mm .14 1

10.0 150mm .15 1

11.0 150mm .20 1

Extension Blade For Drive-Loc

VI Blades High alloy CVM steel, through

hardened, hard chrome finish. OAL blade

length 6.5”. Blades fit all Drive-Loc VI handles.

Item

No. mm OAL lbs. pkg.

6.0 150mm .14 1

ESD Safe Slotted & Phillips

Interchangeable Blade Set, 4 Pc. Includes

ESD Safe handle & 3 interchangeable blades.

Item Slotted:

No. 3.0, 4.0, 6.0mm lbs.

Phillips: 0, 1, 2 .65

ESD Safe Metric Nut Drivers

Interchangeable Blade Set, 8 Pc. Includes

ESD Safe handle & 7 interchangeable blades.

Item

No. lbs. .75

Metric Nut Drivers: 5.0, 5.5, 6.0, 7.0, 8.0, 9.0, 10.0mm

ESD Safe TORX®

Interchangeable Blade Set, 5 Pc. Includes

ESD Safe handle & 4 interchangeable blades.

Item

No. lbs. .70

TORX®: T6, T7, T8, T9, T10, T15, T20, T25

ESD Safe Interchangeable

Combo Blade Set, 11 Pc. Includes ESD Safe

handle & 10 interchangeable blades.

Item

No. lbs. .75

Slotted: 3.0, 4.0, 6.0mm Phillips: 0, 1, 2

Inch Nut Drivers: 3/16, 1/4, 5/16, 11/32, 3/8, 7/16, 1/2”

Wiha Interchangeable Sets

In Durable Pouch

In

Durable

Pouch

In Durable Pouch

In Durable

Pouch

ESD Safe

D

281

28116

28117

28118

28119

28120

28149

28150

28151

28122

28123

28124

28156

28157

28158

28159

28160

28161

28162

28163

28164

28168

28169

28170

28171

28172

28173

28174

28177

28175

28176

28187

28144

10891

10892

10893

10895

Toll Free: (800) 494-6104

wihao Tools that work 10! you ‘._—_. 09‘ - e 9 1| 3 I O A _ D m 2|n.lbs. 1227127 - m m m 0 = O m - m - ESD Sale TorqueVarlo-S Newton 5 g m - — < c:="" ii="" on.="" 0="" g}="" o="" c="" ‘3‘="" -="" hand‘e‘="" 21="" micro="" ans,="" mm="" an="" name:="" and="" handle,="" 21="" micra="" an‘="" micra="" an="" holder="" and="" tolque="" adjustmem="" mm,="" packed="" in="" a="" campam="" torque="" adjustment="" (aol.="" .-—7*a="" -="">

17

D

ESD Safe TorqueVario-S, With

Window Scale EN ISO 6789, BS EN 26789,

ASME B107.14M, +/- 6% Accuracy.

Ergonomic multi-component handle, light

and compact. Handle sizes proportioned to

optimize torque range. Audible & perceptible

click when torque setting has been attained.

With Certificate of accuracy. Pkg. 1

Item Range

No. Inch lbs. Increments mm

15 - 80(in/oz) 2.5 In.oz. 122-127

5 - 10 .2 In.lbs. 122-127

24 Piece ESD Safe Adjustable

TorqueVario-S Bit Set

Certified to EN ISO 6789, BS EN 26789,

ASME B107.14M. Set includes ergonomic

multi-component adjustable TorqueVario-S

handle, 21 Micro Bits, Micro Bit holder and

Torque adjustment tool, packed in a compact

durable storage box.

Item Slotted: 1.5, 2.0, 3.0, 4.0mm

No. Phillips: #00, #0, #1

: T6, T7, T8, T9, T10, T15

Hex Inch: .050, 1/16, 5/64, 3/32,

lbs. 7/64, 1/8, 9/64, 5/32”

1.57 28524 - Handle ESD Safe

Range 5 - 10 Inch lbs.

ESD Safe Slotted Interchangeable

Blades For TorqueVario-S Slotted tip blades

on narrow 5/32 Hex shafts. High alloy CVM

steel, hardened, satin hard chrome finish.

Item Max. Torque

No. mm Inch mm Nm lbs.

3.0 .118 175 0.6 .07

4.0 .157 175 2.5 .07

ESD Safe Interchangeable

Blades For TorqueVario-S

tip blades on narrow 5/32 Hex

shafts. High alloy CVM steel, hardened,

hard chromed.

Item Max. Torque

No. Size mm mm Nm lbs.

T5 175 4.0 0.4 .07

T7 175 4.0 0.9 .07

T8 175 4.0 1.3 .07

T9 175 4.0 2.5 .07

T10 175 4.0 3.8 .07

24 Piece ESD Safe Adjustable

TorqueVario-S Bit Set

Certified to EN ISO 6789, BS EN 26789,

ASME B107.14M. Set includes ergonomic

multi-component adjustable TorqueVario-S

handle, 21 Micro Bits, Micro Bit holder and

Torque adjustment tool, packed in a compact

durable storage box.

Item No. Slotted: 0.8, 1.2, 1.5, 2.0mm

Phillips: #000, #00, #0

: T1, T2, T3, T4, T5, T6

lbs. Hex Metric: 0.7, 0.9, 1.3mm

1.30 Pentalobe: PL1, PL2, PL3, PL4

28500 - Handle ESD Safe

.04 - .46Nm (+/-10%)

Each TorqueVario handle has unique serial

number and certificate of calibration

ESD Safe Adjustable TorqueControl Tools

Includes Certificate

With Certificate

of Calibration

With Certificate of Calibration

24 Piece TorqueVario-S ESD Safe

Micro-Bit Set

Certified to EN ISO 6789, BS EN 26789,

ASME B107.14M. Set includes ergonomic

multi-component adjustable TorqueVario-S

handle, 21 Micro Bits, Micro Bit holder and

Torque adjustment tool.

Item Slotted: 1.5, 2.0, 3.0, 4.0mm

No. Phillips: #00, #0, #1

: T6, T7, T8, T9, T10, T15

Hex Inch: .050, 1/16, 5/64, 3/32,

lbs. 7/64, 1/8, 9/64, 5/32”

1.35 28522 - ESD Safe Handle Range

15-80 Inch/oz.

* +/- 10% (This unit only)

Packed in

a compact

durable

storage box

D

Item Range

No. Nm mm Inch lbs.

.04 - .46 124 4.875” .35

+/- 10%

With Certificate

of Calibration

D

ESD Safe TorqueVario-S Newton

Meter, With Window Scale

Includes Certificate

D

ESD Safe Pentalobe Interchangeable

Blades For TorqueVario-S Newton Meter

Handle tip blades on narrow 5/32 Hex shafts.

High alloy CVM steel, hardened, hard chromed.

Item

No. Size mm mm lbs. pkg.

PL1 175 4.0 .07 1

ESD Safe Bit Holder Adapter For

1/4” Drive Bits Shaft CVM steel, hardened,

corrosion protected. (Not for use in Insulated handles)

Item

No. Size mm mm lbs. pkg.

1/4 162 4.0 .09 1

Item Range

No. Inch lbs. Increments mm

5 - 18 .5 In.lbs. 126-131

ESD Safe TorqueVario-S, W/Window

lbs.

.33

.34

pkg.

1

pkg.

1

pkg.

1

lbs.

.46

285

28522*

28524

28882

288

28805

28809

288

28825

28827

28828

28829

28830

28890

28591

28895

28500

28500*

28818

28426

284

www.wihatools.com

wihao Tools that work 10! you nonrshp soft gvip handle, ESD Safe Dlsswpawe. — 1154.5 "2 "mm ush 0 l , 1 , Flush ‘9 4'0 in, , ‘ {I ,7’13, ‘0,’ <— —=""> m a :q * l * " " 5 5 v v A 4 4 A - q: ‘3 3 ‘ V - — hardened at a hardness oi Appmx. s4 HRC. addmenany indummn hardened at a hardness m

18

Full Flush

Item No. mm Inch Copper Head Wdth

115 4.5 1.0 11.0mm

Precision Cutters, Wide Tapered

Head, Full Flush Cutters drop-forged for an

ideal material structure. Precise aligned cutting

edges are additionally induction hardened at a

hardness of Approx. 64OHRC. Two component

non-slip soft grip handle, ESD Safe Dissipative.

7.5mm

11.0mm

115mm

Precision Cutters Wide Tapered Head

D

Precision Cutters Wide Tapered Head

Item No. mm Inch Copper Head Wdth

115 4.5 1.4 11.0mm

Precision Cutters, Wide Tapered

Head, Bevel Cutters drop-forged for an ideal

material structure. Precise aligned cutting

edges are additionally induction hardened at a

hardness of Approx. 64OHRC. Two component

non-slip soft grip handle, ESD Safe Dissipative.

Bevel

Item No. mm Inch Copper Head Wdth

115 4.5 1.2 11.0mm

Precision Cutters, Wide Tapered

Head, Flush Cutters drop-forged for an ideal

material structure. Precise aligned cutting

edges are additionally induction hardened at a

hardness of Approx. 64OHRC. Two component

non-slip soft grip handle, ESD Safe Dissipative.

7.5mm

11.5mm

7.5mm

11.0mm

115mm

D

Precision Cutters Wide Tapered Head

Flush

D

Item No. mm Inch Copper Head Wdth

115 4.5 1.0 9.5mm

Precision Cutters, Small Tapered

Head With Hollow Ground Back, Flush

Cutters drop-forged for an ideal material

structure. Precise aligned cutting edges are

additionally induction hardened at a hardness

of Approx. 64OHRC. ESD Safe Dissipative.

Precision Cutters Tapered Head

6.0mm

9.5mm

115mm

Flush

D

Item No. mm Inch Copper Head Wdth

115 4.5 1.0 9.5mm

Precision Cutters, Small Tapered

Head With Hollow Ground Back, Semi

Flush Cutters drop-forged for an ideal material

structure. Precise aligned cutting edges are

additionally induction hardened at a hardness

of Approx. 64OHRC. Two component non-slip

soft grip handle, ESD Safe Dissipative.

Precision Cutters Tapered Head

7.5mm

9.5mm

115mm

D

Semi Flush

Flush

Item No. mm Inch Copper Head Wdth

115 4.5 1.0 9.5mm

Precision Cutters, Small Tapered

Head, Flush Cutters drop-forged for an ideal

material structure. Precise aligned cutting

edges are additionally induction hardened at a

hardness of Approx. 64OHRC. Two component

non-slip soft grip handle, ESD Safe Dissipative.

Precision Cutters Tapered Head

6.0mm

9.5mm

115mm

D

Item No. mm Inch Copper Head Wdth

115 4.5 1.0 9.5mm

Precision Cutters, Small Tapered

Head, Semi Flush Cutters drop-forged for an

ideal material structure. Precise aligned

cutting edges are additionally induction

hardened at a hardness of Approx. 64OHRC.

Two component non-slip soft grip handle,

ESD Safe Dissipative. lbs. .19

Semi Flush

7.5mm

9.5mm

115mm

Precision Cutters Tapered Head

Hardened & annealed high carbon tool steel,

induction hardened cutting edges

Box joint for longer tool

life & endurance, mirror

polished finish

ESD standard

IEC 61340-5-1

Welded

double leaf

spring

Protects the hand and

reduces manual effort &

user fatigue

Beveled Cutter Semi-Flush Cutter

Flush Cutter Ultra Full Flush

Wiha ESD Safe

Pliers & Cutters

D

Two component

handle with

non-slip soft

grip surface

lbs. Pkg.

.23 1

lbs. Pkg.

.19 1

lbs. Pkg.

.20 1

lbs. Pkg.

.19 1

lbs. Pkg.

.19 1

lbs. Pkg.

.19 1

Pkg.

1

32710

32706

32708

32704

32702

32705

32703

Toll Free: (800) 494-6104

, w1hao Tools that work 10! you Flush L04 u Q, n "‘ ‘n/ t m 4,“ g d 3 C 5: ﬂ § A 5} - - edges are addmonally indumion hardened at a hardness oi Appmx. wHRc. Twa companem “Ax 4% ‘5} - «» *3» 115 4.5 1.0 10.5mm a?“ c): 9 ‘5‘» o *3; + > ‘wr

19

Precision Cutters Slim Oval Form

Item No. mm Inch Copper Head Wdth

115 4.5 1.2 11.0mm

Precision Cutters, Wide Tapered

Head With Wire Trapping Device, Flush

Cutters drop-forged for an ideal material

structure. Precise aligned cutting edges are

additionally induction hardened at a hardness

of Approx. 64OHRC. ESD Safe Dissipative.

Item No. mm Inch Copper Head Wdth

115 4.5 1.0 10.5mm

Precision Cutters, Slim Oval Head,

Flush Cutters drop-forged for an ideal material

structure. Precise aligned cutting edges are

additionally induction hardened at a hardness

of Approx. 64OHRC. Two component non-slip

soft grip handle, ESD Safe Dissipative.

7.5mm

(10.8mm) w/wire

11.5mm

7.5mm

10.5mm

115mm

Flush

D

Precision Cutters Wide Tapered Head

Flush

D

115mm

Precision Cutters Slim Oval Form

6.0mm

9.5mm

Item No. mm Inch Copper Head Wdth

115 4.5 1.0 10.0mm

Precision Cutters, Slim Oval

Head, Full Flush Cutters drop-forged for an

ideal material structure. Precise aligned cutting

edges are additionally induction hardened at a

hardness of Approx. 64OHRC. Two component

non-slip soft grip handle, ESD Safe Dissipative.

Full Flush

D

Precision Cutters, Wide Oval

Head, Bevel Cutters drop-forged for an ideal

material structure. Precise aligned cutting

edges are additionally induction hardened at a

hardness of Approx. 64OHRC. Two component

non-slip soft grip handle, ESD Safe Dissipative.

115mm

7.5mm

11.5mm

Precision Cutters Wide Oval Form

Bevel

D

Item No. mm Inch Copper Head Wdth

115 4.5 1.4 11.0mm

115mm

7.5mm

11.5mm

Precision Cutters Wide Oval Form

Precision Cutters, Wide Oval

Head, Flush Cutters drop-forged for an ideal

material structure. Precise aligned cutting

edges are additionally induction hardened at a

hardness of Approx. 64OHRC. Two component

non-slip soft grip handle, ESD Safe Dissipative.

Flush

D

Item No. mm Inch Copper Head Wdth

115 4.5 1.2 11.0mm

Precision Cutters, Wide Oval Head

With Wire Trapping Device, Flush Cutters

drop-forged for an ideal material structure.

Precise aligned cutting edges are additionally

induction hardened at a hardness of Approx.

64OHRC. Two component non-slip soft grip

handle, ESD Safe Dissipative.

115mm

7.5mm

11.0mm

Precision Cutters Wide Oval Form

Flush

D

Item No. mm Inch Copper Head Wdth

115 4.5 1.2 11.0mm

Ultra Full Flush

Oblique Angled Cutters, 29O,

Full Flush Oblique Cutters drop-forged for an

ideal material structure. Precise aligned cutting

edges are additionally induction hardened at a

hardness of Approx. 64OHRC. Two component

non-slip soft grip handle, ESD Safe Dissipative.

Oblique Angled Cutters, 29O,

Short Head, Semi Flush Oblique Cutters

drop-forged for an ideal material structure.

Precise aligned cutting edges are additionally

induction hardened at a hardness of Approx.

64OHRC. Two component non-slip soft grip

handle, ESD Safe Dissipative.

115mm

7.5mm

12.0mm

7.5mm

12.0mm

Oblique Angled Cutters

D

Item No. mm Inch Copper Head Wdth

115 4.5 1.0 12.0mm

Item No. mm Inch Copper Head Wdth

115 4.5 1.2 12.0mm

D

Semi Flush

Beveled Cutter Semi-Flush Cutter

Flush Cutter Ultra Full Flush

lbs. Pkg.

.19 1

lbs. Pkg.

.23 1

lbs. Pkg.

.19 1

lbs. Pkg.

.19 1

lbs. Pkg.

.23 1

lbs. Pkg.

.23 1

lbs. Pkg.

.24 1

lbs. Pkg.

.24 1

32711

32712

32714

32716

32720

32721

32714

32716

32720

32721

32724

32726

32724

32726

www.wihatools.com

wihao Tools that work 10! you ' :—. §Md§ 4 m‘s v 4* v i-q:r—a‘: - O_ n I} Snipe 45° Round P‘iers 7 ’1 .A/o 4;“ in <— —=""> n q 4 A "‘ ﬂ 5'“ A A V V q Svm 4 5*.“ - - Lu" Need‘e Nase '9'5 n m ,7 I! ‘9‘ —< 2“=""><— —=""> D <— —="">

20

145mm

Needle Nose,

Bent 90O

ESD Safe Pliers

7.5mm

12.0mm

ESD Safe Pliers, Needle Nose

Pliers, Bent 90O, Smooth Jaws Pliers drop-

forged for an ideal material structure. Precisely

aligned, jaws, hardened. Two component

non-slip soft grip handle, ESD Safe Dissipative.

120mm

Short Round

Nose Pliers

ESD Safe Pliers, Short Round

Nose Pliers, Smooth Jaws Pliers drop-

forged for an ideal material structure. Precisely

aligned, jaws, hardened. Two component non-

slip soft grip handle, ESD Safe Dissipative.

6.5mm

9.5mm

ESD Safe Pliers

D

Item No. mm Inch Head Wdth

145 5 3/4 12.0mm

Item No. mm Inch Head Wdth

120 4 3/4 9.5mm

120mm

Short Flat

Nose Pliers

ESD Safe Pliers, Short Flat Nose

Pliers, Smooth Jaws Pliers drop-forged for

an ideal material structure. Precisely aligned,

jaws, hardened. Two component non-slip soft

grip handle, ESD Safe Dissipative.

6.5mm

9.5mm

ESD Safe Pliers

Item No. mm Inch Head Wdth

120 4 3/4 9.5mm

D

Short Snipe Nose

Item No. mm Inch Head Wdth

120 4 3/4 9.5mm

ESD Safe Pliers, Short Snipe Nose

(Chain Nose) Straight, Serrated Jaws

Pliers drop-forged for an ideal material

structure. Precisely aligned, jaws, hardened.

Two component non-slip soft grip handle,

ESD Safe Dissipative.

120mm

6.5mm

9.5mm

ESD Safe Pliers

D

Bent Snipe

Nose 45O

ESD Safe Pliers, Snipe Nose

(Chain Nose) Bent 45O, Smooth Jaws

Pliers drop-forged for an ideal material

structure. Precisely aligned, jaws, hardened.

ESD Safe Dissipative.

120mm

6.5mm

9.5mm

ESD Safe Pliers

D

Item No. mm Inch Head Wdth

120 4 3/4 9.5mm

Long Needle Nose

ESD Safe Pliers, Long Needle

Nose Pliers, Straight, Serrated Jaws

Pliers drop-forged for an ideal material

structure. Precisely aligned, jaws, hardened.

ESD Safe Dissipative.

145mm

7.5mm

12.0mm

ESD Safe Pliers

D

Item No. mm Inch Head Wdth

145 5 3/4 12.0mm

Oblique Front Cutters, Very Small

Head, 40O, Flush Oblique Cutters drop-

forged for an ideal material structure. Precise

aligned cutting edges are additionally induction

hardened at a hardness of Approx. 64OHRC.

ESD Safe Dissipative.

130mm

6.2mm

9.7mm

Oblique Front Cutters

Item No. mm Inch Copper Head Wdth

130 5.1 0.8 8.5mm

Flush

D

130mm

End Cutters Extra Slim

2.9mm 6.0mm

7.0mm

Tip Width

End Cutters, Extra Slim, Semi Flush

End Cutters drop-forged for an ideal material

structure. Precise aligned cutting edges are

additionally induction hardened at a hardness

of Approx. 64OHRC. ESD Safe Dissipative.

D

Semi Flush

Item No. mm Inch Copper Tip Wdth

130 5.1 0.6 4.1mm

115mm

End Cutters Wide Head

16.5mm 7.5mm

11.5mm

End Cutters, Wide Head, Flush

End Cutters drop-forged for an ideal material

structure. Precise aligned cutting edges are

additionally induction hardened at a hardness

of Approx. 64OHRC. ESD Safe Dissipative.

Flush

D

Item No. mm Inch Copper Head Wdth

115 4.5 1.4 11.0mm

lbs. Pkg.

.21 1

lbs. Pkg.

.17 1

lbs. Pkg.

.16 1

lbs. Pkg.

.20 1

lbs. Pkg.

.27 1

lbs. Pkg.

.20 1

lbs. Pkg.

.16 1

lbs. Pkg.

.18 1

lbs. Pkg.

.21 1

32748

32750

32752

32748

32750

32752

32742

32744

32746

32742

32744

32746

32728

32732

32734

32732

32734

Toll Free: (800) 494-6104

wihao Tools [hat work fol you - ESD Sale Preclslon Flush Cunin — A o - ESD Saie Long Nose Pllers wnn Return Spring Exira long cuiiers ior iiai and SVSTEM 4 Slotted & Phllllps 5 PC. Set Er prOtUT ' Hardened steel ietum spring Glare flee black linish Tesiea ESD Sale handie mm nonrsiip soft grip suﬂace, component nonrslip soii gnp handle. Custom Case son grip handie ESD Sale Dissmaiive. o 2, 0.3, 0 4, 0.5, 0.6, 0.8mm

21

ESD Safe Tool Set In Canvas Pouch

11 piece ESD Safe Pliers & Slotted/

Phillips Precision Drivers Set In Custom Case

ESD Safe Pliers & Cutters

4.5” Tapered Flush Cutters

4.5” Snipe Nose Pliers

4.375” Oblique Cutters

5.7” Long Nose Pliers

ESD Safe Screwdrivers

Slotted 2.0, 2.5, 3.0, 3.5mm

Phillips #00, 0, 1

lbs. 2.43

11 Piece Set, 4 ESD Safe Pliers,

Slotted & Phillips Screwdrivers Pliers drop-

forged for an ideal material structure. Two

component non-slip soft grip handle.

D

4 piece ESD Safe Pliers Set

Set includes:

4.5” Oval Side Cutters

5.75” Long Nose Pliers

4.75” Flat Nose Pliers

4.375” Oblique Cutters

lbs. 1.02

4 Piece ESD Safe Pliers Set In

Custom Case Pliers drop-forged for an ideal

material structure. Two component non-slip

soft grip handle. ESD Safe Dissipative.

11 pc. ESD Safe Pliers, Tweezers &

SYSTEM 4 Precision Set In Custom Case:

ESD Safe Pliers & Cutters

4.5” Oval Side Cutters

5.75” Long Nose Pliers

4.75” Flat Nose Pliers

4.375” Oblique Cutters

SYSTEM 4 Set in separate pouch

ESD Safe Conductive Precision Handle

Slotted: 1.5, 2.0, 3.0 & 4.0mm

Phillips: #000, 00, 0 & 1

ESD Safe Tweezers:

AA SA ESD & 7a SA ESD

lbs. 1.32

11 Pc. Set, 4 ESD Safe Pliers,

SYSTEM 4 Slotted & Phillips 5 Pc. Set &

2 ESD Safe Tweezers Pliers drop-forged for

an ideal material structure. Two component

non-slip soft grip handle. ESD Safe Precision

handle & 4 CVM tool steel blades. Tweezers

anti-static conductive, ESD Safe Hypo

allergenic, anti-magnetic stainless.

ESD standard IEC 61340-5-1

D

ESD standard IEC 61340-5-1

Item No. mm Inch Strips AWG Pkg. lbs.

165 6.5 30 to 20 1 .25

Proturn ESD Safe Wire Stripper

C70 special tool steel. Glare free, black finish.

ESD Safe handle with non-slip grips. Strips

0.2, 0.3, 0.4, 0.5, 0.6, 0.8mm

Glare free

black finish

ESD standard IEC 61340-5-1

Hardened steel

return spring

Tested ESD Safe handle with

non-slip soft grip surface,

protects the hand and reduces

manual effort & user fatigue

Wiha ESD Safe Proturn

Pliers & Cutters

A

165mm

ESD Safe Wire Stripper

Item No. mm Inch Pkg. lbs.

160 6.3 1 .18

Proturn ESD Safe Long Nose

Pliers, Serrated Jaws C70 special tool steel.

Glare free, black finish. ESD Safe handle with

non-slip grips.

160mm

ESD Safe Long Nose Pliers

Surface resistance of handles is 106 - 109 Ohms

BC

BA

C

proturn

D

proturn

Serrated

Jaws

A = 30mm

B = 12mm

C = 4mm

D

A = 2mm

B = 30mm

C = 3mm

ESD Safe Precision Flush Cutting

Diagonal Cutters Low wear lap joint, riveted

and able to withstand high levels of load.

Lightweight action, clean cutting. Long life

edge is achieved through additional induction

hardening to approx. 64HRC. Special C70 tool

steel. Two component non-slip soft grip handle,

ESD Safe Dissipative.

D

Item No. mm Inch Head Wdth

133 5.25 .5”

ESD Safe Diagonal Cutters

ESD Safe Long Nose Pliers With

Return Spring Extra long cutters for flat and

round cables. Serrated jaws. Long life edge is

achieved through additional induction harden-

ing to approx. 64HRC. Special C70 tool steel

forgings. Two component non-slip soft grip

handle, ESD Safe Dissipative.

ESD Long Nose Pliers

D

Item No. mm Inch Head Wdth

165 6.5 .625”

ESD Safe Tool Set In Canvas Pouch

lbs. Pkg.

.18 1

lbs. Pkg.

.24 1

32790

32791

32790

32791

45810

45811

45810

45811

32793

32760

32762

www.wihatools.com

wihao Tools that work 10! you — — — 2.» '2- 2‘ 21‘ 2‘

22

Item No. mm Inch AWG Pkg. lbs.

127 5.0 18/1mm 1 .14

Proturn ESD Safe 45° Precision

Cutters/Flush Cut ESD standard IEC 61340-5-1.

C70 special tool steel. Glare free, black finish.

ESD Safe handle with non-slip grips.

127mm

ESD Safe Diagonal Cutters

45°

Angle

Item No. mm Inch AWG Pkg. lbs.

140 5.5 16/1.3mm 1 .15

Proturn ESD Safe 21° Precision

Cutters/Flush Cut ESD standard IEC 61340-5-1.

C70 special tool steel. Glare free, black finish.

ESD Safe handle with non-slip grips.

140mm

ESD Safe Diagonal Cutters

21°

Angle

B

A

C

B

A

C

Wiha ESD Safe Proturn Pliers & Cutters

Surface resistance of handles is 106 - 109 Ohms

proturn

D

A = 10mm

B = 9mm

C = 2mm

D

A = 13mm

B = 12mm

C = 3mm

133mm

ESD Safe Diagonal Cutters

21°

Angle

proturn

B

A

C

Item No. mm Inch AWG Pkg. lbs.

133 5.25 14/1.6mm 1 .14

Proturn ESD Safe 21° Precision

Cutters/Flush Cut ESD standard IEC 61340-5-1.

C70 special tool steel. Glare free, black finish.

ESD Safe handle with non-slip grips.

A = 10mm

B = 10mm

C = 2mm

D

Item No. mm Inch AWG Pkg. lbs.

140 5.5 14/1.6mm 1 .16

Proturn ESD Safe 45° Precision

Cutters/Flush Cut ESD standard IEC 61340-5-1.

C70 special tool steel. Glare free, black finish.

ESD Safe handle with non-slip grips.

140mm

ESD Safe Diagonal Cutters

45°

Angle

B

A

C

proturn

D

A = 13mm

B = 12mm

C = 2.5mm

Item No. mm Inch Pkg. lbs.

152 6.0 1 .17

Proturn ESD Safe Round Nose

Pliers ESD standard IEC 61340-5-1.

C70 special tool steel. Glare free, black finish.

ESD Safe handle with non-slip grips.

152mm

ESD Safe Round Nose Pliers

Item No. mm Inch AWG Pkg. lbs.

127 5.0 18/1mm 1 .16

Proturn ESD Safe 21° Precision

Cutters/Flush Cut ESD standard IEC 61340-5-1.

C70 special tool steel. Glare free, black finish.

ESD Safe handle with non-slip grips.

127mm

ESD Safe Diagonal Cutters

21°

Angle

BA

C

B

A

C

proturn

A = 2mm

B = 22mm

C = 3mm

D

A = 13mm

B = 12mm

C = 3mm

Item No. mm Inch Pkg. lbs.

160 6.3 1 .18

Proturn ESD Safe Flat Nose

Smooth Jaws Pliers C70 special tool steel.

Glare free, black finish. ESD Safe handle with

non-slip grips.

160mm

ESD Safe Flat Nose Pliers

B

A

C

Item No. mm Inch Pkg. lbs.

152 6.0 1 .18

Proturn ESD Safe Bent Nose

Pliers ESD standard IEC 61340-5-1. C70

special tool steel. Glare free, black finish.

ESD Safe handle with non-slip grips.

152mm

ESD Safe Bent Nose Pliers

BA

C

proturn

D

A = 2mm

B = 32mm

C = 3mm

A = 2mm

B = 30mm

C = 4mm

D

45821

45822

45823

45824

45814

45820

45812

45813

Toll Free: (800) 494-6104

wihao Tools that work 10! you

23

26 Piece ESD Safe Pliers, Precision

Screwdrivers, Micro Bit Set & ESD Tweezer

Set in Canvas Pouch

ESD Safe Proturn Strippers, Pliers & Cutters

6.5” Wire Stripper

6.3” Long Nose Pliers

6.0” Bent Nose Pliers

5.25” 21° Precision Cutters

ESD Safe Slotted & Phillips Precision Drivers

Slotted: 2.0, 2.5, 3.0mm & Phillips: 0, 1

ESD Micro Bit Handle, Micro Bit Extension

& 14 Micro Bits 4mm

Hex: .7, .9, 1.3, 1.5, 2.0, 2.5, 3.0mm

Torx: T4, T5, T6, T7, T8, T9, T10

ESD Safe Tweezer: 00 SA ESD -

120mm Heavy Duty Strong, Tapered To Strong Point

lbs. 1.74

26 Pc. Set, Proturn ESD Safe

Pliers, Precision Slotted & Phillips

Screwdrivers, Precision Micro Bit Set &

ESD Safe Tweezers ESD Proturn Pliers

glare free, black finish, ESD Safe non-slip

soft grips. ESD Safe Precision Slotted &

Phillips screwdrivers, CVM tool steel blades.

Precision ESD Safe Micro Bit handle holds

Micro Bit extension and 4mm Micro bits.

Anti-static Tweezer conductive, ESD Safe

Hypo allergenic, anti-magnetic stainless.

ESD standard IEC 61340-5-1

Surface resistance

of handles is

106 - 109 Ohms

proturn

Wiha ESD Safe Proturn

Pliers/Cutters, Precison

Drivers & MicroBits Set

D

Professional Quality ESD Tweezers

ESD SAFE • STATIC DISSIPATIVE • HYPO ALLERGENIC COATED • TEXTURED GRIPPING SURFACE

Item No. Description wt.

AA SA ESD-130mm .09

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

Universal Fine Point Tweezers

Item No. Description wt.

GG SA ESD - 130mm .09

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

Sturdy Long, Fine Round Points

Item No. Description wt.

3 SA ESD - 120mm .08

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

Fine Round Points For Assembly

Item No. Description wt.

7a SA ESD - 120mm .08

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

Curved Extra Fine Rounded Tips

Item No. Description wt.

SS SA ESD - 135mm .08

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

Long Narrow Body Low Force

Item No. Description wt.

3c SA ESD - 110mm .08

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

Fine Round Points Shorter

Item No. Description wt.

2 SA ESD - 120mm .08

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

Reduced Body To Medium Point

Item No. Description wt.

4 SA ESD - 110mm .08

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

Very Fine Points/Tapered To Tip

Item No. Description wt.

2a SA ESD - 120mm .08

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

Flat Round Tip Smooth Sides

Item No. Description wt.

5 SA ESD - 110mm .08

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel, anti-

magnetic and acid resistant.

Extra Fine Points/Tapered To Tip

D

45890

44501

44502

44503

44504

44505

44506

44507

44508

44509

44510

www.wihatools.com

wihao Tools that work 10! you Wiha Professional Quality ESD Safe Tweezers , 3—2 ’ ——— —— )3 —- .)—— ——ﬁ— — )3 in» —— m n — i ’n =—:n ——— an — )- 3—, :“—— .)ID 3—. ) ———

24

Item No. Description wt.

5bb SA ESD-107mm .08

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

Extra Fine Points Bent

30O - 3mm Long Tips

Wiha Professional Quality ESD Safe Tweezers

Item No. Description wt.

59 SA-SMD ESD-117mm .08

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

Flat Bent 35O -

2mm Diameter Grip Radius

Item No. Description wt.

8b SA ESD - 120mm .08

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

MicroTip Bent 30O 1.6mm

Item No. Description wt.

PSF SA ESD-125mm .09

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

Item No. Description wt.

13 SA ESD - 120mm .08

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

MicroTip For Chips Angled

1.6 x 1 x 1mm

Long Rounded to 1.0mm Wide

No Serration

Item No. Description wt.

5abb SA ESD - 117mm .08

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

Angled Extra Fine Points

Bent 30O - 3mm Long Tips

Item No. Description wt.

7abb SA ESD - 120mm .08

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

Item No. Description wt.

58 SA-SMD ESD-117mm .08

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

Flat Bent 35O, 3mm Diameter Grip

Curved Extra Fine, 3mm Long

Straight Tip

Item No. Description wt.

SSbb SA ESD-140mm .08

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

Narrow Body Low Force Bent 35O -

3mm Tip

Item No. Description wt.

12 SA-SMD ESD-120mm .09

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

MicroTip 45O Hook 1x1x2mm

Item No. Description wt.

40 SA ESD - 145mm .11

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

Universal Blunt Tip Serrated

Item No. Description wt.

22 SA ESD - 150mm .10

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

Narrow Rounded Tip Serrated,

Guide Pin

Item No. Description wt.

51 SA ESD - 130mm .08

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

Item No. Description wt.

50 SA ESD - 120mm .08

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

Holds 0.8 to 2mm Diameter

Holds 1.5 to 3mm Diameter

Item No. Description wt.

52 SA ESD - 120mm .08

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

Holds 3.5 to 7mm Diameter

Item No. Description wt.

54 SA ESD - 120mm .08

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

Angled 3.5 to 7mm Diameter

Item No. Description wt.

53 SA ESD - 120mm .08

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

Holds 6.5 to 10mm Diameter

44518

44520

44521

44522

44523

44524

44525

44526

44527

44528

44529

44530

44511

44512

44513

44514

44515

Toll Free: (800) 494-6104

wihao Tools that work 10! you Wiha Professional Quality ESD Safe Tweezers === ‘ m *- ——— ,m u p— ——— —— «m b:- — m — —@ {Am- : l 7 gm

25

Item No. Description wt.

7 SA ESD - 120mm .08

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel, anti-

magnetic and acid resistant.

Angled & Slightly Bent

With Extra Fine Tips

Item No. Description wt.

00 SA ESD - 120mm .09

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

Heavy Duty Strong Tweezers

Tapered To Strong Point

Item No. Description wt.

1 SA ESD - 120mm .08

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

ESD Safe General Purpose Fine Point

Item No. Description wt.

11SA-SMD ESD-117mm .08

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

MicroTip 30O Bend & 0.5mm Slot Milled

Item No. Description wt.

22b SA ESD - 155mm .10

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

Narrow Body, Bent, Long Guide

Pin, Serrated

Item No. Description wt.

PSF SA ESD S -125mm .09

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

Blunt Tips - 1.0mm Wide Serrated

Item No. Description wt.

F SA ESD - 120mm .08

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

Flat and Broad Tips 3mm Wide

Item No. Description wt.

8ab SA-SMD ESD-120mm .08

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

MicroTip Straight & 0.5mm Slot Milled

Item No. Description wt.

19 SA-SMD ESD-120mm .08

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

MicroTip 30O Bent & Angled

With 0.5 Slot

Item No. Description wt.

R10 SA ESD - 117mm .07

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

Chip Holding Curved Fine MicroTip

Item No. Description wt.

72a SA ESD - .07

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

Wafer Tweezer

Item No. Description wt.

4b SA ESD - 110mm .08

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

Very Fine Points 40° Tapered To Tip

Item No. Description wt.

89 SA ESD - 125mm .08

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

9mm Wide With

Back Stop Pins - Wafer

Item No. Description wt.

91 SA ESD - 125mm .08

Static dissipative, ESD Safe hypo allergenic tweezers

made from Vommaloy. Special stainless steel,

anti-magnetic and acid resistant.

Angled 12mm Wide Flat,

Back Stop - Wafer

Wiha Professional Quality ESD Safe Tweezers

SYSTEM 4 Premium ESD Safe

Micro Bit Set, 28 Pcs. Includes Wiha ESD

Safe Precision Handle, 1/4” to 4mm Adapter,

100mm Bit Extension, ESD Safe Tweezers &

21 Micro Bits.

Item No. SYSTEM 4 Micro Bit Set

75993 Micro Bits:

Slotted: 0.8, 1.5, 2.0, 2.5,

3.0, 3.5mm

Phillips: 000, 00, 0, 1, 2

: T1, T2, T3, T4, T5,

T6, T7, T8, T9, T10

ESD Safe Tweezers:

5SA ESD, 7aSA ESD, 2ASA ESD,

AASA ESD, OOSA ESD

lbs. .95

75993

D

Premium ESD Safe Micro Bit & Tweezers Set

S

44531

44532

44533

55531

55532

55533

55534

55535

55536

55537

55539

55538

55546

55547

www.wihatools.com

wihao Tools [hat work fol you

26

Numerical Index by Item Number

32726 19

32728 20

32732 20

32734 20

32742 20

32744 20

32746 20

32748 20

32750 20

32752 20

32760 21

32762 21

32790 21

32791 21

32793 21

36200 14

36204 14

36206 14

36208 14

36209 14

36218 14

36219 14

36224 14

36260 14

36289 14

38701 13

38790 13

41105 13

41106 13

44501 23

44502 23

44503 23

44504 23

44505 23

44506 23

44507 23

44508 23

44509 23

44510 23

44511 24

44512 24

44513 24

44514 24

44515 24

44518 24

44520 24

44521 24

44522 24

44523 24

44524 24

44525 24

44526 24

44527 24

44528 24

44529 24

44530 24

44531 25

44532 25

44533 25

45810 21

45811 21

10891 16

10892 16

10893 16

10895 16

26903 8

26904 8

26905 8

26911 8

26912 8

26922 8

26958 7

26959 7

26960 7

26961 7

26970 7

26971 8

26972 8

26973 8

26974 8

26975 7

26976 7

26977 7

26978 7

26979 7

26980 7

26981 7

26982 7

26983 7

26985 7

26994 7

27208 4

27210 4

27212 4

27215 4

27218 4

27220 4

27222 4

27223 4

27224 4

27225 4

27227 4

27228 4

27230 4

27232 4

27234 4

27235 4

27237 4

27238 4

27240 4

27242 4

27243 4

27290 4

27302 4

27305 4

27307 4

27310 4

27314 4

27316 4

27320 4

27322 4

27324 4

27326 4

27390 4

27393 4

27397 5

27398 4

27399 4

27505 6

27507 6

27509 6

27510 6

27513 6

27515 6

27520 6

27525 6

27530 6

27535 6

27537 6

27539 6

27541 6

27543 6

27545 6

27547 6

27549 6

27590 6

27591 6

27701 6

27703 6

27705 6

27707 6

27709 6

27711 6

27713 6

27715 6

27720 6

27721 6

27722 6

27725 6

27730 6

27735 6

27740 6

27745 6

27750 6

27755 6

27760 6

27790 6

27791 6

27801 5

27802 5

27803 5

27804 5

27805 5

27811 5

27817 5

27823 5

27829 5

27835 5

27841 5

27847 5

27850 5

27851 5

27852 5

27853 5

27854 5

27855 5

27856 5

27857 5

27890 5

27894 5

27899 5

27920 5

28000 8

28002 7

28003 7

28004 7

28005 7

28006 7

28007 7

28008 7

28009 7

28010 7

28011 7

28012 7

28013 7

28014 7

28015 7

28016 7

28017 7

28106 15

28107 15

28108 15

28109 15

28110 15

28112 15

28114 15

28116 16

28117 16

28118 16

28119 16

28120 16

28122 16

28123 16

28124 16

28126 15

28127 15

28128 15

28129 15

28130 15

28132 15

28133 15

28134 15

28135 15

28136 15

28137 15

28138 15

28139 15

28140 15

28142 15

28143 15

28144 16

28149 16

28150 16

28151 16

28156 16

28157 16

28158 16

28159 16

28160 16

28161 16

28162 16

28163 16

28164 16

28168 16

28169 16

28170 16

28171 16

28172 16

28173 16

28174 16

28175 16

28176 16

28177 16

28180 13

28187 16

28486 15

28500 17

28522 17

28524 17

28526 17

28591 17

28805 17

28809 17

28818 17

28825 17

28827 17

28828 17

28829 17

28830 17

28882 17

28890 17

28895 17

30240 14

30242 14

30244 14

30246 14

30248 14

30292 14

31150 14

31151 14

31152 14

32702 18

32703 18

32704 18

32705 18

32706 18

32708 18

32710 18

32711 19

32712 19

32714 19

32716 19

32720 19

32721 19

32724 19

Item No. Pg. Item No. Pg. Item No. Pg. Item No. Pg. Item No. Pg.

Toll Free: (800) 494-6104

wihao Tools [hat work fol you

27

45812 22

45813 22

45814 22

45820 22

45821 22

45822 22

45823 22

45824 22

45890 23

55531 25

55532 25

55533 25

55534 25

55535 25

55536 25

55537 25

55538 25

55539 25

55546 25

55547 25

75008 10

75012 10

75015 10

75018 10

75020 10

75025 10

75030 10

75035 10

75040 10

75093 12

75094 12

75095 12

75096 12

75097 12

75105 10

75110 10

75115 10

75120 10

75125 10

75307 10

75309 10

75313 10

75315 10

75320 10

75322 10

75325 10

75330 10

75332 10

75340 10

75342 10

75350 10

75352 10

75354 10

75356 10

75358 10

75360 10

75362 10

75364 10

75366 10

75368 10

75370 10

75372 10

75602 9

75603 9

75604 9

75605 9

75606 9

75607 9

75608 9

75609 9

75610 9

75611 9

75612 9

75613 9

75614 9

75615 9

75616 9

75617 9

75618 9

75619 9

75620 9

75621 9

75622 9

75623 9

75624 9

75626 9

75627 9

75628 9

75629 9

75630 9

75631 9

75632 9

75633 9

75634 9

75635 9

75636 9

75637 9

75638 9

75639 9

75640 9

75641 9

75642 9

75643 9

75644 9

75645 9

75646 9

75647 9

75648 9

75649 9

75650 9

75651 9

75652 9

75653 9

75654 9

75655 9

75656 9

75657 9

75658 9

75659 9

75660 9

75661 9

75662 9

75663 9

75664 9

75665 9

75666 9

75667 9

75668 9

75669 9

75670 9

75671 9

75672 9

75673 9

75674 9

75675 9

75676 9

75677 9

75681 9

75683 9

75701 10

75702 10

75703 10

75704 10

75705 10

75706 10

75707 10

75708 10

75709 10

75710 10

75715 10

75720 10

75735 10

75742 10

75743 10

75744 10

75745 10

75746 10

75747 10

75748 10

75801 8

75810 10

75811 10

75812 10

75813 10

75814 10

75815 10

75816 10

75817 10

75820 10

75821 10

75822 10

75823 10

75824 10

75825 10

75826 10

75827 10

75900 8

75901 8

75902 8

75965 13

75968 11

75971 11

75977 11

75980 11

75982 8

75984 8

75986 8

75987 8

75988 8

75991 12

75992 12

75993 25

75994 12

75995 11

75996 11

91118 7

92092 5

Prop65 WARNING: This product could expose you

to chemicals including Vinyl Chloride, Ethylene Glycol, Ni

or CrVl, which are known to the state od California to cause

cancer or reproductive harm. For more information go to

www.P65warnings.ca.gov/

Item No. Pg. Item No. Pg. Item No. Pg. Item No. Pg. Item No. Pg.

www.wihatools.com

0 “WWW WIHA — WINNER OF THE - MX AWARD 2014. Mb 0. ET.“ GERMANYS BEST SME. m Tools that work for you A time =-' wince =‘ ”I'M" l E 3‘ 0 1 I § 3’ a y la wihae _ wjhue _ wings _ wjﬂqw .. wiha- “\un mum-mm 4'W‘k an“

Subject to change

without notice

Corporation

®Torx is a registered trademark of

Acument Intellectual Properties LLC.

Catalog Item No. 99945

version - 3/1/19

PROFESSIONAL ESD SAFE TOOLS

.wo

Wiha Quality Tools

1348 Dundas Circle

Monticello, MN 55362

tel: 763.295.6591

fax: 763.295.6598

To:

Wiha Tools Canada Ltd.

www.wihatools.ca

Brampton, ONT L6T 4X4

tel: 866.494.0096 or 763.295.6591

fax: 763.295.6598

(800) 494-6104

fax: (800) 494-7456

cservice@wihatools.com

www.wihatools.com

99001.wo - TorqueControl Catalog

99977.wo - Pliers/Crimpers Catalog

99934.wo - Hex Tools Catalog

99002.wo - Screwdrivers Catalog

99919.wo - Insulated Catalog

99951.wo - Bits Catalog

99006.wo - Tech Tools Catalog

99914.wo - TORX Catalog

99004.wo - Shop Tools Catalog

2019 2019

2019 2019 2019 2019

99007.wo - Merchandise Catalog

Professional ESD Safe Tools Datasheet by Wiha

Products related to this Datasheet
