Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
5019530505 | |
|---|---|
DigiKey Part Number | 900-5019530505TR-ND - Tape & Reel (TR) 900-5019530505CT-ND - Cut Tape (CT) 900-5019530505DKR-ND - Digi-Reel® |
Manufacturer | |
Manufacturer Product Number | 5019530505 |
Description | CONN HEADER SMD R/A 5POS 1MM |
Manufacturer Standard Lead Time | 20 Weeks |
Customer Reference | |
Detailed Description | Connector Header Surface Mount, Right Angle 5 position 0.039" (1.00mm) |
Datasheet | Datasheet |
EDA/CAD Models | 5019530505 Models |
Product Attributes
Type | Description | Select All |
|---|---|---|
Category | ||
Mfr | ||
Series | ||
Packaging | Tape & Reel (TR) Cut Tape (CT) Digi-Reel® | |
Part Status | Active | |
Connector Type | ||
Contact Type | Male Pin | |
Pitch - Mating | ||
Number of Positions | ||
Number of Rows | 1 | |
Row Spacing - Mating | - | |
Number of Positions Loaded | All | |
Style | ||
Shrouding | Shrouded - 4 Wall | |
Mounting Type | ||
Termination | Solder | |
Fastening Type | Locking Ramp | |
Contact Length - Mating | - | |
Contact Length - Post | - | |
Overall Contact Length | - | |
Insulation Height | 0.130" (3.30mm) | |
Contact Shape | Square | |
Contact Finish - Mating | Gold | |
Contact Finish Thickness - Mating | 3.90µin (0.099µm) | |
Contact Finish - Post | Gold | |
Contact Material | Phosphor Bronze | |
Insulation Material | Polyamide (PA), Nylon | |
Features | Solder Retention | |
Operating Temperature | -40°C ~ 105°C | |
Ingress Protection | - | |
Material Flammability Rating | UL94 V-0 | |
Insulation Color | Natural | |
Current Rating (Amps) | Varies by Wire Gauge | |
Voltage Rating | 50V | |
Mated Stacking Heights | - | |
Contact Finish Thickness - Post | 1.97µin (0.050µm) | |
Applications | Automotive, General Purpose, Industrial, Medical | |
Base Product Number |
In-Stock: 14,756
Check for Additional Incoming Stock
Quantity
All prices are in THB
Cut Tape (CT) & Digi-Reel®
| Quantity | Unit Price | Ext Price |
|---|---|---|
| 1 | ฿32.83000 | ฿32.83 |
| 10 | ฿27.91800 | ฿279.18 |
| 100 | ฿23.73480 | ฿2,373.48 |
| 500 | ฿21.18286 | ฿10,591.43 |
Tape & Reel (TR)
| Quantity | Unit Price | Ext Price |
|---|---|---|
| 1,300 | ฿19.40025 | ฿25,220.33 |
| 2,600 | ฿18.47450 | ฿48,033.70 |
| 3,900 | ฿17.95358 | ฿70,018.96 |
| 6,500 | ฿17.31850 | ฿112,570.25 |
| 9,100 | ฿16.91246 | ฿153,903.39 |
| 13,000 | ฿16.49260 | ฿214,403.80 |
